OPTIONAL CONNECTIONS

Connecting to a Computer
Connect the tablet to a computer to transfer files.
1. Connect your tablet to the computer.
With the included USB cable: Plug the small end of the cable into the USB 2.0 high speed
connector of the tablet. Plug the large end of the cable into an available USB 2.0 high
speed port on the computer.
2. When your tablet is connected, slide down the USB icon then touch icon USB
connected.
3. Mount the storage
Touch button Transfer files(MTP) to mount the tablet's built-in storage. When it is mounted,
you can copy files to or from your tablet.
11

SPECIFICATIONS

Processor RK3326 (Quad-core Cortex-A35 up to 1.5GHz)
RAM 2GB DDR3
16GB flash
Storage
Micro SD card slot (max128GB supported)
Display
7'' 1024*600, Capacitive touchscreen
IEEE 802.1 1 b/g/n
Wi-Fi Networking
3.5mm headphone
Audio Output
PC Interface
USB 2.0 high speed
Front facing camera(0.3MP)
Additional Features
Built-in microphone
Bluetooth
4.0
Operating System
Android 9.0 Pie
Power
Rechargeable Li-poly battery Power Adapter (DC 5V, 1.5A)
Playback Time (hours)
Up to 6 hours music, 3 hours video, 3 hours web browsing

TROUBLESHOOTING

1. Device doesn't power on.
• Reboot your device after charging it for 30 minutes.
• Shortly press your power button to check if it lights up in case your device is in sleep
mode.
• Press the power button for 20 seconds.
• Start a hard reset by pressing the reset button with a pin if there is reset button on your
actual device.
2. Device doesn't take charge.
• Keep your device into power for 30 minutes if it was completely drained.
• Check and make sure the charger is properly inserted into charging port.
• Try another outlet or compatible charger.
Rear camera (2.0MP)
1X1W speaker
