Button Overview - Sitecom WLX-5100 Installationsanleitung

Wi-Fi range extender
Dualband AC750
LED + PORT OVERVIEW
2
2.4 GHz
(Connection between
Range Extender and Router)
5 GHz
(Connection between
Range Extender and Router)
WLAN
Power
LAN
OPS
Network Port

BUTTON OVERVIEW

On/Off Switch
Connect to the 2.4 GHz frequency
Press 2-5 sec = connect a device to the Range Extender
Press 5-10 sec = connect the Range Extender to the Router
Connect to the 5 GHz frequency
Press 2-5 sec = connect a device to the Range Extender
Press 5-10 sec = connect the Range Extender to the Router
Press both buttons 15+ sec =
Reset mode, reset to factory default.
3
