6. RS232 Pinouts

EL-41AT
PIN
1
2
3
4
5
6
7
8
9
RS-232 transmission format:
• Baud Rate: 9600 bps
• Data bit: 8 Bits Parity: None
• Stop Bit: 1 bit
6.1 Commands Sets
COMMAND
"I" + "1"
"I" + "2"
"I" + "3"
"I" + "4"
"S" + "1"
"S" + "0"
"P" + "1"
"P" + "0"
Definition
NC
Tx
Rx
NC
GND
NC
NC
NC
NC
Page 6
Remote Control Console
PIN
1
2
3
4
5
6
7
8
9
ACTION
PORT 1 ON
PORT 2 ON
PORT 3 ON
PORT 4 ON
ENABLE SIGNAL ENHANCE
DISABLE SIGNAL ENHANCE
POWER ON
POWER OFF
Definition
NC
Rx
Tx
NC
GND
NC
NC
NC
NC
