1. Disconnect power to the Indicator.
2. Turn the Indicator to access the
back. If a V1 Receiver is installed,
remove it from the plug-in connector
on the Indicator.
3. Plug in the Receiver's ribbon cable
connector from below with the
cable's red stripe to the right.
4. Remove the Receiver's Velcro strip
backing and set the Receiver in
place in the lower right corner of the
Indicator housing. Press the
Receiver firmly against the housing
to seat the Velcro adhesive.
7
Ref. 3800 2280, Ver 2004-06
