System Map: Front View with LCD Panel Open

3
Model A
15.6" (39.62cm)
1. PC Camera
2. *Camera LED
*When the camera is in use, the LED
will be illuminated.
3. Built-In Array Microphone
4. LCD
2 1 3
4
5
6
7
Figure 3 - Front View with LCD Panel Open
3 2 1
4
Model B
17.3" (43.94cm)
6
7
5. Power Button
6. Keyboard
7. Touchpad & Buttons
3
5
9
