keyless entry InstrUCtIOn • User GUIde
• Unlock: Press the button on the remote transmitter once to unlock the car. The parking
lights will gleam twice. Press and hold two seconds to release trunk.
• Lock: Press the button on the remote transmitter once to lock the car. The parking lights
will gleam once and all electronical windows will close themselves in 30 seconds.
• Trunk releasing: Press the button on the remote transmitter once to release the trunk.
The parking lights will gleam three times.
• Location: There are two ways to determine the location of your car. Press the button
one time. The parking lights gleam three times. When locked, press the button on the
remote transmitter once. The parking lights will gleam three times.
• Learning code: Press the learning code button on the 'Brain Case' once. When the park-
ing lights are ON and you can press any button on the remote transmitter, you are in
the learning mode. When the parking lights are OFF, the learning mode is finished. By
repeating this action, you can add a maximum of four remote transmitters to your 'Brain
Case'. If you add more than four remote transmitters, the first four will be deleted.
InstallInG the keyless entry system
See diagrams.
• Negative / positive output option for trunk releasing:
Plug in position 1-2 for +12V output;
Plug in position 2-3 for -12V output (to GND).
AL
ROL
• Time options of central door locking system:
Plug in position 2-3 is 0,5 seconds for electric central lock;
Plug in position 1-2 is 3,5 seconds for pneumatic central lock.
ER FROM
PCB
CK
