WARNING AND NOTICE:

1. This product is only applicable to the child aged 18-60M.
2. The guardian must read this instruction book carefully before use
otherwise it might compromise the child' s safety. Please retain this
instruction book permanently for future reference!
3. Can't be used near fire, heat, or water!
4. Installation should be done by the adult.
5. The guardian must not go away when the child is riding.
6. Keep away from the street and road.
7. Limited weight capacity: 25KG, Can't be overloaded!
8. If the parts are not installed correctly, it can be dangerous!
9. The seat is rotatable. The child should sit facing the adult and put feet
on the pedal plates to avoid accident when the adult is pushing forward
the tricycle
10. If the entangled object is attached to the tricycle, there is a danger
of tangling or su ocation. Do not connect it to the tricycle and use it
under adult supervision!
WARNING AND MAINTENANCE:
1. Do put the packing materials and protective materials into designated
rubbish bin after unpacking.
2. Please inspect the tightness of fastening parts every time before use.
The recommended tightening torque is 18-20 N.m. Failed inspection
might cause damage to the child.
3. Do not ride under damp, cold or scorching environment.
4. Avoid collision with any other thing hard.
Product purpose:
This product has two uses:
- The child may step on the pedal plate to run the tricycle.
- The adult may push the handspike to move the tricycle forward while
the child putting feet on the pedal plates.
1. CARTON PARTS LIST
1. Frame
2. Handlebar
3. Front Wheel
4. Front Fork
5. Splash Guard of front wheel
6. Rear Wheel
7. Seat Handrail
8. Car head with music
9. Canopy
10. Pedal Plate
11. Back basket
12. Controlling handle
13A. String nails
13B. Screws
13C. Nuts
13D. Hexagonal wrench
Note: In case of more parts required, please notify our after-sales service
in sequence of serial number.
2. INSTALLATION PROCEDURE
1. Installation of Splash Guard
2. Installation of front fork. The clutch switch can be rotated back and
forth to control the switch clutch.
3. Installation of Handlebar.
According to the illustration, attach the accessory to the frame and
tighten the screw when it is inserted.
4. Installation of car head with music. Install the car head on the
handlebar and lock the switch. According to the illustration, attach the
accessory to the frame and tighten the screw when it is inserted.
5. Installation of real wheel. Insert with a string nails to lock the wheel
and pull it outwards to check for locking
6. Installation of basket. Put the basket on the frame
7. Installation of Controlling handle. The two parts will be assembled and
the plug will be ejected.
8. Installation of push handle.
8.1. The red wrench must be pulled down and inserted into the frame
during installation.
8.2. After the pusher is installed, the plug must be ejected and the wrench
upward to lock.
9. Installation of seat. Install the seat on the frame, and then insert the
seat screw from the round hole at the bottom of the frame and lock it
with a Hexagonal wrench.
10. Installation of pedal plate. Align the foot pedal with the pendant on
the seat and attach it to the frame.
11. Installation of canopy. Insert the canopy down on both sides of the seat.
12. Installation completion diagram
PLEASE CHECK AND CONFIRM WHETHER THE SCREWS ARE
TIGHTENED AFTER INSTALLATION. NEVER MISS ANYTHING!
