PLACING THE MACHINE IN SERVICE
LUBRIFICATION
Always use of an air line lubricator with these machine.
Every eight hours' operation, if a lubricator is not used on the compressed air
network, inject 1/2 to 1cm
through the machine's inlet connection.
3
Model
E230125
Model
Free speed
rpm
E230125
4000
* k = measurement uncertainty in dB ** k = measurement uncertainty in m/s²
WE, EXPERT S.A.S., 6/8 RUE GUSTAVE EIFFEL - BP 99 - 91 423 MORANGIS CEDEX FRANCE, DECLARE UNDER OUR OWN RESPONSIBILITY THAT THE
WE, EXPERT S.A.S., 6/8 RUE GUSTAVE EIFFEL - BP 99 - 91 423 MORANGIS CEDEX FRANCE, DECLARE UNDER OUR OWN RESPONSIBILITY THAT THE
EXPERT
EXPERT S.A.S., 6/8 RUE GUSTAVE EIFFEL - BP 99 - 91 423 MORANGIS CEDEX FRANCE, DECLARE UNDER OUR OWN RESPONSIBILITY THAT THE
PRODUCT E230125 – EXPERT 1" AIR IMPACT WRENCH
- IS IN CONFORMITY WITH THE «MACHINERY» DIRECTIVE 2006/42/CE
- AND IS IN CONFORMITY WITH THE PROVISIONS OF THE HARMONISED EUROPEAN STANDARD EN ISO 11148-6: 2012
EN ISO 12100:2010
EN ISO 15744:2008
EN ISO 28927-2:2009
• BEFORE EACH OPERATION, CHECK:
- Only use suitable
safety devices, bush and pin for mounting one of these cases on a drilled driving
square.
- The drive square condition (no marks, cracks or excessive wear).
- The condition of the safety devices (bush and pin) on the drilled square as well as the draw
bead on the non-drilled square.
Square
Impact
Breakaway
drive
rate
Torque
''
N.m
1
800
2170
Air consumption
Working pressure
l/min
312
CE DECLARATION OF CONFORMITY
CE DECLARATION OF CONFORMITY
EMERGENCY
GATE VALVE
sockets and flogging spanner accessories, (''IMPACT'') as well as
EXPERT
Noise level
Pressure dB(A)
Power dB(A)
k*
104
3
115
Weight
bar
kg
6,2
9,84
Pressure dB(C)
k*
k*
3
122
3
Dimensions
mm
315 X 125 X 195
27.07.2012
EXPERT QUALITY MANAGER
Vibrations
level
m/s
2
k**
23,9
2,86
