5. TECHNICAL CHARACTERISTICS

a. Technical specifications:
- Radio frequency 2.4 GHz FHSS
- Range: approximately 150 m in free field.
b. LCD monitor
- Screen: 9cm (3,5") in diagonal
- Power supply: 5V
- Lithium Battery
- Power consumption: 600 mA
- Channels: 1
- Dimensions: 100 x 80 x 19(mm)
- Weight: 110 g
- Operating temperature: 0°C to + 60° approx.
c. Camera
- Power supply : 5V
- Power consumption: 500 mA
- Light sensitivity: 1,5 lux
- Infrared Led: 15 infrared diodes.
- Camera lens: 1/4'' CMOS colour H58° V58°
- Weight (without bracket): 70 g
- Operating temperature: -15°C to 55° approx.
- Dimensions: 85 x 65 x 28 (mm)

6. MAINTENANCE

The warranty is void if the parts are dismantled. Clean the outside only with a soft and dry
cloth. Before cleaning, disconnect and switch off the video surveillance system.
CAUTION
Do not use any acid or alcohol based or other similar cleaning product or solvent. You may
damage the appliance and the vapours are explosive and dangerous for your health.
Do not use any tool which can be voltage conductor (metallic brush, sharp tool...or other)
for cleaning.

7. TROUBLESHOOTING

With this video surveillance system, you have bought a high technology and ready to use
product.
All parts are supplied to use completely your kit.
Nevertheless if you encounter problems or dysfunctions, you can remedy these defects by
reading the following table:
CFI EXTEL O'CUP - 02/2013 - V1
GB5
