7 Technical Specifi cations
Model
L7 110 XA
Max. SPL @ 10% THD
128 dB half space
(70 Hz – 12 kHz averaged)*
Max. SPL peak @ 10% THD
131 dB half space*
Max. SPL peak calculated
137 dB half space
Frequency response +/- 3 dB
95 Hz – 19 kHz*
Frequency response -10 dB
75 Hz – 19 kHz*
Power amp output (peak
2000 W
power)
Amp type
Class D – biamped
Active protective circuits
Under-voltage, thermal, short
circuit, over-current protection,
subsonic filter, look ahead
temperature control, peak, RMS
and multiband limiters
Bass woofer
-
Low/Mid speaker
1x 10", 2.5" voice coil
HF driver
1", 1.4" voice coil
Horn directivity
80° x 60° CD horn, rotatable
Active x-over frequency
2 kHz FIR X-Over
with 60 dB/oct.
Analog ports
1x XLR Combo In bal.,
1x XLR Thru bal.,
1x XLR DSP Out
Max. input level
+20 dBu
Filter presets
Flat, Monitor, Low Cut, Remote
Network port
Ethercon RJ45, 1x In, 1x Thru
DSP functions
Fully parametric 10-band EQ
with variable filter characteris-
tics, High-Pass Filter, Low-Pass
Filter, Polarity, Level, Delay,
Limiter, Mute
Remote software
HK Audio DSP CONTROL
(Windows, Mac OS, iPad to
follow)
Sampling rate
96 kHz
System latency
less than 2.6 ms
Mains connector
1x Powercon NAC3 In,
100–240 V
Power consumption
1 A / 100–240 V nominal
according to EN 62368-1
Clustering angle
-
Angles up
30°
Pole mount
HK Audio DuoTilt 3/7
Suspension points
5x M8 (AP-8)
Grips
2x standard flush-mount
handles
Housing
Hybrid (birch multiplex / MDF)
Front grille
2 mm metal grille backed with
black acoustic foam
Finish
Black acrylic enamel
Optional accessories
Rain covers, Satellite Add-On
M20 XLR, Speaker Stand Add-
On Package, M20 mounting
pole, Tilt bracket (TB-45N,
TB-45NQ), Attachment point
(AP-8), Tilt Unit
Dimensions (WxHxD)
36.5 x 54.5 x 30.5 cm
14-21/64 x 21-29/64 x 12-1/64"
Weight
20 kg* / 44.1 lbs*
*) Preliminary data
L7 112 FA
L7 112 XA
130 dB half space
130 dB half space
(70 Hz – 12 kHz averaged)
(70 Hz – 12 kHz averaged)*
131 dB half space
131 dB half space*
137 dB half space
137 dB half space
64 Hz – 19 kHz
95 Hz – 19 kHz*
55 Hz – 20 kHz
70 Hz – 19 kHz*
2000 W
2000 W
Class D – biamped
Class D – biamped
Under-voltage, thermal, short
Under-voltage, thermal, short
circuit, over-current protection,
circuit, over-current protection,
subsonic filter, look ahead
subsonic filter, look ahead
temperature control, peak, RMS
temperature control, peak, RMS
and multiband limiters
and multiband limiters
-
-
1x 12", 2.5" voice coil
1x 12", 2.5" voice coil
1", 1.7" voice coil
1", 1.7" voice coil
70° x 50° CD horn, rotatable
70° x 50° CD horn, rotatable
1.6 kHz FIR X-Over
1.6 kHz FIR X-Over
with 60 dB/oct.
with 60 dB/oct.
1x XLR Combo In bal.,
1x XLR Combo In bal.,
1x XLR Thru bal.,
1x XLR Thru bal.,
1x XLR DSP Out
1x XLR DSP Out
+20 dBu
+20 dBu
Flat, Boost, Low Cut, Remote
Flat, Monitor, Low Cut, Remote
Ethercon RJ45, 1x In, 1x Thru
Ethercon RJ45, 1x In, 1x Thru
Fully parametric 10-band EQ
Fully parametric 10-band EQ
with variable filter characteris-
with variable filter characteris-
tics, High-Pass Filter, Low-Pass
tics, High-Pass Filter, Low-Pass
Filter, Polarity, Level, Delay,
Filter, Polarity, Level, Delay,
Limiter, Mute
Limiter, Mute
HK Audio DSP CONTROL
HK Audio DSP CONTROL
(Windows, Mac OS, iPad to
(Windows, Mac OS, iPad to
follow)
follow)
96 kHz
96 kHz
less than 2.6 ms
less than 2.6 ms
1x Powercon NAC3 In,
1x Powercon NAC3 In,
100–240 V
100–240 V
1 A / 100–240 V nominal
1 A / 100–240 V nominal
according to EN 62368-1
according to EN 62368-1
70°
-
-
30°
HK Audio DuoTilt 3/7
HK Audio DuoTilt 3/7
4x M8 (AP-8)
5x M8 (AP-8)
2x HK Audio MultiGrip
1x HK Audio MultiGrip,
1x standard flush-mount
handles
Hybrid (birch multiplex / MDF)
Hybrid (birch multiplex / MDF)
2 mm metal grille backed with
2 mm metal grille backed with
black acoustic foam
black acoustic foam
Black acrylic enamel
Black acrylic enamel
Rain covers, Satellite Add-On
Rain covers, Satellite Add-On
M20 XLR, Speaker Stand Add-
M20 XLR, Speaker Stand Add-
On Package, M20 mounting
On Package, M20 mounting
pole, Tilt bracket (TB-45N,
pole, Tilt bracket (TB-45N,
TB-45NQ), Attachment point
TB-45NQ), Attachment point
(AP-8), Tilt Unit
(AP-8), Tilt Unit
37.5 x 67.5 x 37 cm
37.5 x 67.5 x 31 cm
14-49/64 x 25-37/64 x 14-9/16"
14-49/64 x 25-37/64 x 12-13/64"
23 kg / 50.7 lbs
22 kg* / 48.5 lbs*
L7 115 FA
L7 118 Sub A
130 dB half space
129 dB half space
(70 Hz – 12 kHz averaged)*
(72 Hz – 100 Hz averaged)
131 dB half space*
131 dB half space
137 dB half space
135 dB half space
60 Hz – 19 kHz*
42 Hz – X-over
50 Hz – 19 kHz*
38 Hz – X-over
2000 W
2000 W
Class D – biamped
Class D
Under-voltage, thermal, short
Under-voltage, thermal, short
circuit, over-current protection,
circuit, over-current protection,
subsonic filter, look ahead
subsonic filter, look ahead tem-
temperature control, peak, RMS
perature control, peak, RMS and
and multiband limiters
multiband limiters
-
1x 18", 4" voice coil
1x 15", 3" voice coil
-
1", 1.7" voice coil
-
60° x 40° CD horn, rotatable
-
1.5 kHz FIR X-Over
-
with 60 dB/oct.
1x XLR Combo In bal.,
2x XLR Combo In bal.,
1x XLR Thru bal.,
2x XLR Thru bal., 1x XLR DSP Out
1x XLR DSP Out
+20 dBu
+20 dBu
Flat, Boost, Low Cut, Remote
Front, Cardioid 1:1, Cardioid 2:1,
Remote
Ethercon RJ45, 1x In, 1x Thru
Ethercon RJ45, 1x In, 1x Thru
Fully parametric 10-band EQ
Fully parametric 10-band EQ with
with variable filter characteris-
variable filter characteristics,
tics, High-Pass Filter, Low-Pass
High-Pass Filter, Low-Pass Filter,
Filter, Polarity, Level, Delay,
Polarity, Level, Delay, Limiter, Mute
Limiter, Mute
HK Audio DSP CONTROL
HK Audio DSP CONTROL
(Windows, Mac OS, iPad to
(Windows, Mac OS, iPad to follow)
follow)
96 kHz
96 kHz
less than 2.6 ms
less than 2.6 ms
1x Powercon NAC3 In,
1x Powercon NAC3 In,
100–240 V
1x Powercon NAC3 Thru, 100–240 V
1 A / 100–240 V nominal
1.9 A / 100–240 V nominal accor-
according to EN 62368-1
ding to EN 62368-1
60°
-
-
-
HK Audio DuoTilt 3/7
1x M20
3x M8 (AP-8)
-
2x HK Audio MultiGrip
2x HK Audio MultiGrip
Hybrid (birch multiplex / MDF)
Birch multiplex
2 mm metal grille backed with
2 mm metal grille backed with
black acoustic foam
black acoustic foam
Black acrylic enamel
Black acrylic enamel
Rain covers, Satellite Add-On
Rain covers, Splash-proofing,
M20 XLR, Speaker Stand Add-
casters, Satellite Add-On M20 XLR,
On Package, M20 mounting
M20 mounting pole, Tilt-Unit
pole, Tilt bracket (TB-45N,
TB-45NQ), Attachment point
(AP-8), Tilt Unit
45.5 x 71.5 x 45.5 cm
55.5 x 56.5 x 69 cm
17-29/32 x 28-5/32 x 17-29/32"
21-27/32 x 22-1/4 x 27-5/32"
31 kg* / 68.3 lbs*
40.4 kg / 89.1 lbs
