QUICK START GUIDE
PAC K AG E CO N T E N T S
• 1 x ZOTAC ZBOX pico
• 1 x Mounting bracket
• 2 x Mounting screws
• 1 x AC adapter
• 1 x CTIA<=>OMTP adapter
• 1 x USB drive with O/S driver
• 1 x Warranty Card
• 1 x User Manual & Quick Start Guide
I /O
1. USB 3.0 Type-C port
2. DisplayPort
3. HDMI output
4. Analog audio jack (3.5mm)
5. Ethernet port
6. MicroSD memory card slot
7. Power input (DC 5V, 3A)
8. USB 3.0 ports
9. Power button
INITIAL SETUP INSTRUCTIONS
1. Connect USB devices
2. Connect a display
3. Connect to a home network (optional)
4. Connect power adapter
5. Press the power button to turn on the ZBOX pico.
2
1 2 3 4
7 8
5
6
9
