SETUP AND USE

INSTALLATION TO Z-LINK
FIGURE 1.1
For the Z-Link - Remove the cape retainer
®
clip.
FIGURE 1.3
Insert the mounting bracket into the jaw,
lining up the holes. Insert and tighten the
mounting screws.
OR T-LINK
® ®
FIGURE 1.2
Remove the mounting bracket from the light
unit.
Reattach the light unit to the mounting
bracket.
FIGURE 1.4
5
