Exploded View Arc XL
1. Front panel
2. Front fan filter
3. 2 x USB 3.0, 2 x USB 2.0
4. Removable/rotatable upper hdd cage
5. Removable/repositionable lower hdd cage
6. Hdd mounting bracket
7. Bottom dust filter
8. Top dust filter
9. Window side panel
10. Additional SSD mounts behind M/B plate
11. Integrated fan controller
12. Offset top radiator mounting
