Delivery
•
Digital Rotor Gauge
•
1 piece 3 Volt button cell
Technical data
Measure Range:
Measurable Jaw Depth:
Resolution:
Accuracy:
Display:
Material:
Power-Off:
Battery:
Battery Replacement:
Once Display start not turning on or flashing:
•
Pull out the battery compartment holder and remove the old battery. Never try to apply force or pry.
•
Replace the new battery in the battery compartment holder. Pay attention to the correct polarity.
•
Insert the battery holder into the battery compartment.
•
Please recycle the used batteries at a proper collection center.
Function Keys:
•
ON/O Key: 1x press turn unit on / press again set to zero. Automatic Power-Off after approximate 2
minutes.
•
mm/in/F Key: switch between inch, metric and inch fractions.
•
HOLD Key: Display value is held
Care and Maintenance
•
Keep the instrument clean and dry.
•
Avoid shocks or impacts.
•
Avoid strong magnetic fields.
•
Clean instrument with a soft cloth. DO NOT use any type of solvent.
DO NOT immerse instrument in liquid.
In case of contact with liquid:
Splash liquid may cause display failure. Wipe off the liquid, be sure liquid between sliding body and beam is
completely dried. Then reset instrument at the delivered condition.
Reset to delivered condition:
In order to reset instrument to its delivered condition, please remove battery for 30 seconds. Insert the
battery again to restart the instrument.
Disposal
•
If you dispose the device, observe the applicable safety
and environmental protection.
•
The digital vernier caliper contains material that may
be taken for recycling.
•
Batteries should be disposed of in accordance with
applicable law.
www.swstahl.de
0 - 80 mm / 0 - 3.2 "
28 mm / 1.10 "
0,01 mm / 0.0005 "
± 0,025 mm / ± 0.001 "
LCD display
Solid hardened stainless steel
Automatic Power-Off
1 piece CR2032. 3 Volt
SW-Stahl GmbH
An der Hasenjagd 3
D-42897 Remscheid
Tel. +49 (0) 2191 / 46438-0
Fax +49 (0) 2191 / 46438-40
E-Mail: info@swstahl.de
72347L
