Seite 1
User Manual TuneCommand AV for iPod ® ™ Introduction...
Seite 2
TuneCommand AV delivers the flexibility and convenience that iPod users desire. Using wireless radio frequency technology, TuneCommand AV works from up to 120 feet away from your stereo. Please review this User Manual carefully so that you can be sure to get the most from your new Belkin product.
Seite 3
Legend Volume up Battery-life and range indicator Play/pause Skip forward Skip backward Volume down Shuffle button Battery door release button (on the back) Repeat button iPod connector Signal indicator Dock adapter Battery door (on the bottom) Stereo Stereo Video out Power in AV out line out...
Seite 4
Operating Instructions STEP 1 - TuneCommand AV Dock Setup iPod mini 4GB 6GB 1. Place the TuneCommand AV Dock in the desired ��� ��������� ��� ����� ����� ������� location on your home entertainment system. iPod 20GB 2. Insert the barrel plug of the included AC U2 Special ���...
Seite 5
Remote Control until the button snaps back into place and the battery tray is securely shut. 3. Now press any of the Remote Control’s buttons for the TuneCommand AV Remote Control and Dock to pair up. The green lights on the Dock and the Remote Control blink when the first button-press command from the Remote Control reaches the Dock correctly.
Seite 6
Operating Instructions You can now use your TuneCommand AV Remote Control to control the iPod’s play/pause, skip forward, skip backward, and volume up/down functions. In addition, you can conveniently control the shuffle and repeat functions, using the two small round buttons. Each press of a button advances the setting to the next stage.
Remote Control’s red light will blink, following the green or amber blink. If you see this happen, the low battery should be replaced soon with a new one of the same type (CR 2032). Your TuneCommand AV will continue to function normally until the battery is exhausted. GREEN...
Seite 8
Using the Multi-Clip The clip allows you to wear the Remote Control on a belt, or around your neck with the lanyard. Do not slide on SNAP Attaching the multi-clip to the Remote Control How to wear on a belt Using the surface mount Using the Multi-Clip | 08...
Dock is not powering on when plugged in. Ensure the AC power adapter is completely plugged into the wall and “power in” port on the TuneCommand AV Dock. Ensure your iPod is fully inserted into the connector on the top of the Dock.
Specifications Operating Range: Up to 120 ft. (36.6m) Transmission Method: Radio frequency Frequency: 2.44GHz Remote Battery: CR 2032 3V Remote Dimensions: 3.5” x 1.5” x 0.5” (8.9cm x 3.8cm x 1.3cm) (not including belt clip; 0.75” (1.9cm) max depth including belt clip) Remote Weight (including battery): 0.8 oz.
Seite 11
Information FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the product: F8Z065ea to which this declaration relates: Has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
Belkin Corporation warrants the Belkin product for three years. What will we do to correct problems? Product Warranty. Belkin will repair or replace, at its option, any defective product free of charge (except for shipping charges for the product). What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin Corporation for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin Corporation determines that the Belkin...
Seite 13
Belkin Corporation reserves the right to review the damaged Belkin product. All costs of shipping the Belkin product to Belkin Corporation for inspection shall be borne solely by the purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship the damaged equipment to Belkin Corporation, Belkin may designate, in its sole discretion, an equipment repair facility to inspect and estimate the cost to repair such equipment.
Manuel de l’utilisateur TuneCommand AV pour iPod ® ™ Introduction...
Seite 18
Conçu pour vous permettre de vous déplacer n’importe où chez nous tout en écoutant votre musique, le TuneCommand AV offre toujours plus de polyvalence aux utilisateurs d’iPod. Grâce à la technologie sans fil par radiofréquences, la télécommande TuneCommand fonctionne jusqu’à...
Seite 19
Légende Augmenter volume État de la pile et indicateur de Lecture / Pause portée Piste suivante Piste précédente Baisser volume Bouton Lecture aléatoire Bouton de déclenchement Bouton Répéter du couvercle du compartiment à piles (à l’arrière) Connecteur iPod Indicateur de Adaptateur signal d’ancrage...
Seite 20
ÉTAPE 1 – Mise en route de la base d’ancrage iPod mini 4 Go 6 Go TuneCommand AV ��� ��������� ��� ����� ����� ������� 1. Placez la base d’ancrage du TuneCommand à iPod 20 Go l’endroit désiré, sur votre chaîne audiovisuelle. édition ��� ��������� ��� ����� ����� �������...
Seite 21
à la base. NOTE : Si vous retirez ou remplacez la pile, vous devez débrancher l’adaptateur secteur de la base TuneCommand AV et le rebrancher afin d’établir une nouvelle connexion avec la télécommande.
Seite 22
Chaque pression sur le bouton permet d’avancer au réglage suivant. Lorsque vous l’utilisez avec l’iPod video, nano ou photo, le TuneCommand AV vous permet de faire défiler vos vidéos (iPod vidéo seulement), photos ou présentations, le tout sans fil ! NOTE : •...
Seite 23
Si tel est le cas, la pile faible doit être remplacée promptement par une nouvelle pile de même type (CR 2032). Le TuneCommand fonctionne toutefois normalement jusqu’à épuisement de la pile.
Seite 24
Utilisation de la pince La pince vous permet de porter la télécommande à la ceinture, ou autour de votre cou grâce au cordon. Ne pas glisser PRESSER Comment poser la pince sur la télécommande Comment fixer à la ceinture Utilisation du support de montage Utilisation de la pince | 08...
- Répétez les ÉTAPES 1 et 2 de mise en route. • La télécommande ne fonctionne pas après le remplacement de la pile. Après avoir remplacé la pile, débranchez l’adaptateur secteur de la base TuneCommand AV et rebranchez-le afin d’établir une nouvelle connexion avec la télécommande. •...
Caractéristiques techniques Portée de fonctionnement : Jusqu’à to 36,6 mètres Mode de transmission : Fréquences radio Fréquence : 2,44 GHz Pile de la télécommande : CR 2032, 3 V Dimensions de la télécommande : 8,9 cm x 3,8 cm x 1,3 cm (sans pince de ceinture ;...
Seite 27
Déclaration FCC DÉCLARATION DE CONFORMITÉ À LA RÉGLEMENTATION FCC EN MATIÈRE DE COMPATIBILITÉ ÉLECTROMAGNÉTIQUE Nous, Belkin Corporation, sis au 501 West Walnut Street , Compton CA, 90220, États-Unis, déclarons sous notre seule responsabilité que le produit : F8Z065ea auquel se réfère la présente déclaration : a été...
Vous devez prendre les mesures suivantes pour faire réparer ou entretenir votre produit Belkin : 1. Écrivez à Belkin Corporation au 501 W. Walnut St., Compton CA 90220, États-Unis, à l’attention de : Service Client, ou appelez au (800)-223-5545 dans les 15 suivant l’événement. Préparez-vous à fournir les informations suivantes : a.
Seite 29
BELKIN COMPONENTS NE PEUT EN AUCUN CAS ÊTRE TENU RESPONSABLE DE DOMMAGES ACCESSOIRES, DIRECTS, INDIRECTS OU MULTIPLES, Y COMPRIS, MAIS SANS S’Y LIMITER, LA PERTE DE REVENUS OU D’AFFAIRES DÉCOULANT DE LA VENTE OU DE L’UTILISATION DE TOUT PRODUIT BELKIN, MÊME LORSQU’IL A ÉTÉ AVISÉ DE LA PROBABILITÉ DES DITS DOMMAGES.
Einleitung Mit dem TuneCommand AV können Sie die Wiedergabe von Musik und Videos praktisch von überall in Ihrer Wohnung aus steuern. Dieses praktische Gerät bietet iPod-Benutzern genau die Flexibilität, die sie sich wünschen. Durch die Verwendung von Funktechnologie funktioniert die TuneCommand AV Fernbedienung in einer Reichweite von bis zu 40 Metern von Ihrer Stereoanlage.
Seite 35
Übersicht Lautstärke + Anzeige für Batterielaufzeit Wiedergabe/ und Reichweite Pause Nächster Titel Vorheriger Titel (vorwärts) (zurück) Lautstärke - Shuffle-Knopf Batteriefach- (Zufallsauswahl) Auslöseknopf Repeat-Knopf (auf der Rückseite) (Wiederholen) iPod-Anschluss Signal-Anzeige Dock-Adapter Batteriefachdeckel (an der Unterseite) Stereo AV-Ausgang Stereo Line- Netzeingang Ausgang Videoausgang DC 12 V / S-Video 0,8 A...
Bedienungsanweisungen SCHRITT 1 – Einrichtung des TuneCommand AV Docks iPod mini 4 GB 6 GB 1. Stellen Sie das TuneCommand AV Dock an einem ��� ��������� ��� ����� ����� ������� geeigneten Platz auf Ihrer Heimkinoanlage auf. iPod 20 GB, U2- 2.
Seite 37
Batterieabdeckung wieder auf die Fernbedienung, bis der Knopf wieder einrastet. 3. Drücken Sie jetzt einen beliebigen Knopf der Fernbedienung, damit sich die TuneCommand AV Fernbedienung und das Dock aufeinander abstimmen. Die grünen Anzeigen des Docks und der Fernbedienung blinken auf, wenn der erste Knopfdruck- Befehl der Fernbedienung ordnungsgemäß...
Seite 38
Bedienungsanweisungen Jetzt können Sie mit der TuneCommand AV Fernbedienung folgende Funktionen des iPod-Geräts bedienen: Wiedergabe/Pause, vorwärts (nächster Titel) / zurück (vorheriger Titel) sowie die Lautstärkeregulierung. Außerdem können Sie Wiederholung und Zufallsauswahl mit den beiden kleinen runden Knöpfen bedienen. Jeder Knopfdruck bringt die Einstellung auf die nächste Ebene.
Wenn die Batterie entladen ist, leuchtet nach der grünen bzw. orangen Anzeige die rote Anzeige auf der Fernbedienung auf. Ist dies der Fall, sollten Sie die entladene Batterie möglichst bald durch eine Batterie desselben Typs (CR 2032) ersetzen. Die TuneCommand AV Fernbedienung funktioniert auf die gewohnte Weise, bis die Batterie erschöpft ist.
Verwendung des Multi-Clip Mit dem Clip können Sie die Fernbedienung an einem Gürtel befestigen oder mit der Trageschnur um den Hals binden. Nicht schieben EINRASTEN Den Multi-Clip an der Fernbedienung anbringen Befestigung am Gürtel Halterung verwenden Verwendung des Multi-Clip | 08...
Dock schaltet sich nach Anschluss nicht ein. Überprüfen Sie, ob das Netzteil ordnungsgemäß an die Steckdose und an den Netzeingang (power in) des TuneCommand AV Docks angeschlossen ist. Stellen Sie sicher, dass der iPod fest an den Anschluss an der Oberseite des Docks angeschlossen ist.
Technische Daten Reichweite: Bis zu 36,6 m Übertragungsmethode: Funk Frequenz: 2,44 GHz Fernbedienungsbatterie: CR 2032 3 V Abmessungen der Fernbedienung: 8,9 cm x 3,8 cm x 1,3 cm (ohne Gürtelclip; max. Tiefe mit Gürtel-Clip: 1,9 cm) Gewicht der Fernbedienung (mit Batterie): 22,6 g Abmessungen des Docks: 8,9 cm x 8,9 cm x 2,5 cm Gewicht des Docks: 96,4 g Clip/Halterung/Trageschnur: 13,2 g...
Seite 43
FCC-Erklärung KONFORMITÄTSERKLÄRUNG ZUR EINHALTUNG DER FCC-BESTIMMUNGEN ÜBER DIE ELEKTROMAGNETISCHE VERTRÄGLICHKEIT Wir, Belkin Corporation, eine Gesellschaft mit Sitz in 501 West Walnut Street, Compton, CA 90220, USA, erklären hiermit in alleiniger Verantwortung, dass dieses Produkt mit der Artikel-Nr. F8Z065ea , auf das sich diese Erklärung bezieht, nachweislich den Grenzwerten für digitale Geräte der Klasse B gemäß...
Service. Um Unterstützung von Belkin zu bekommen, gehen Sie nach folgenden Schritten vor: 1. Nehmen Sie Kontakt mit Belkin Corporation, 501 W. Walnut St., Compton CA 90220, Attn: Customer Service auf oder wenden Sie sich telefonisch innerhalb von 15 Tagen nach dem Vorfall an Belkin: (800)-223- 5546.
Seite 45
Belkin-Produkts an die Belkin Corporation zum Zweck der Überprüfung entstehen, sind vollständig durch den Käufer zu tragen. Wenn Belkin nach eigenem Ermessen entscheidet, dass es unpraktisch ist, das beschädigte Gerät an die Belkin Corporation zu schicken, kann Belkin nach eigenem Ermessen eine Reparaturstelle damit beauftragen, das Gerät zu überprüfen und einen Kostenvoranschlag für die Reparaturkosten des Gerätes zu machen.
Mediante tecnología de radiofrecuencia inalámbrica, TuneCommand funciona a una distancia de hasta 35 metros de su equipo estéreo. Por favor, lea atentamente este Manual del usuario para asegurarse de que saca el máximo partido a su nuevo producto Belkin.
Seite 51
Leyenda Subir volumen Indicador de nivel y duración Reproducir/ de la batería Pausa Título siguiente Título anterior Bajar volumen Botón de reproducción aleatoria Botón para abrir el compartimento de la Botón de batería repetición (en la parte posterior) Conector de Indicador de Adaptador dock iPod...
4 GB 6 GB TuneCommand AV ��� ��������� ��� ����� ����� ������� 1. Coloque la base de TuneCommand AV sobre su iPod sistema de entretenimiento en casa, donde prefiera. 20 GB, U2 ��� ��������� ��� ����� ����� �������...
Seite 53
Control remoto deslizándola hasta que se cierre correctamente. 3. A continuación, presione cualquiera de los botones del Control remoto TuneCommand AV y la Base para que se acoplen. Las luces verdes de la Base y del Control remoto parpadearán cuando la primera orden tras pulsar un botón del Control remoto logre...
Seite 54
Cada vez que presiona un botón, se pasa a la siguiente opción. Cuando lo utilice con iPod vídeo, nano o photo, TuneCommand AV le permitirá desplazarse para ver sus fotos, presentaciones y vídeos (sólo con iPod vídeo), ¡a...
Seite 55
ámbar. Si observa que esto sucede, se debe sustituir en breve la batería baja por otra nueva del mismo tipo (CR 2032). Su TuneCommand AV seguirá funcionando normalmente hasta que se agote la batería.
Seite 56
Utilización del clip multiuso El clip le permite llevar el Control remoto sujeto al cinturón o alrededor del cuello con la correa incluida. No lo deslice Fijación del clip multiusos al Control remoto Cómo ajustarlo al cinturón Utilización de la superficie de montaje Utilización del clip multiuso | 08...
Asegúrese de que el adaptador de alimentación CA está completamente insertado en el enchufe y en el puerto de entrada de alimentación de la Base TuneCommand AV. Asegúrese de que su iPod esté correctamente insertado en el conector de la parte superior de la Base.
Especificaciones Distancia operativa: Hasta 36,6 m Método de transmisión: Radiofrecuencia Frecuencia: 2,44 GHz Batería del control remoto: CR 2032, 3 V Dimensiones del control remoto: 8,9 cm x 3,8 cm x 1,3 cm (sin incluir el clip para cinturón; profundidad máxima con el clip: 1,9 cm) Peso del control remoto (batería incl.): 22,6 g Dimensiones de la Base: 8,9 cm x 8,9 cm x 2,5 cm Peso de la Base: 96,4 g...
Seite 59
Declaración de la FCC (Comisión de comunicaciones de EE.UU.) DECLARACIÓN DE CONFORMIDAD CON LAS NORMATIVAS DE LA FCC SOBRE COMPATIBILIDAD ELECTROMAGNÉTICA Nosotros, Belkin Corporation, con sede en 501 West Walnut Street, Compton, CA 90220 (EE.UU.), declaramos bajo nuestra sola responsabilidad que el producto: F8Z065ea al que hace referencia la presente declaración:...
Seite 60
únicamente, o si Belkin Corporation determina que el producto Belkin se ha instalado de un modo inadecuado, alterado de algún modo o forzado. La garantía del producto de Belkin no lo protege de los desastres naturales (que no sean relámpagos) tales como inundaciones, terremotos, guerras, vandalismo, robo, desgaste natural debido al uso normal, desgaste, agotamiento, obsolescencia, mal uso, daños a causa de alteraciones la alimentación (p.
Seite 61
Garantía limitada de 3 años para los productos de Belkin Corporation 2. El servicio de atención al cliente de Belkin le informará sobre cómo enviar la factura y el producto Belkin y sobre cómo proceder con su reclamación. Belkin Corporation se reserva el derecho de revisar el producto Belkin dañado. Todos los costes de envío del producto Belkin a Belkin Corporation para su inspección correrán a cargo del comprador exclusivamente.
Progettato per permettervi di controllare il contenuto audio e video da qualsiasi punto della vostra casa, il TuneCommand AV offre tutti i comfort di cui ha bisogno un amante dell’iPod. Grazie alla trasmissione wireless in radiofrequenza, il TuneCommand AV funziona fino a 40 metri di distanza dallo stereo.
Seite 67
Legenda Volume Su Indicatore della copertura e Riproduzione/ dello stato delle Pausa batterie Avanti Indietro Volume Giù Selezione casuale Apertura sportello della batteria Ripetizione (sul retro) brano Connettore iPod Indicatore di Adattatore dock segnale Sportello della batteria (sulla parte inferiore) Uscita Uscita Uscita Video...
Fig. 1 4. Scegliere l’adattatore corrispondente al proprio iPod e inserire nell’apposito alloggiamento sulla base dock del TuneCommand (Fig. 1). Gli Aprire e rimuovere l’adattatore adattatori per iPod video e iPod nano sono compresi nella confezione dell’iPod acquistato. 5. Inserire l’iPod nella base dock.
Seite 69
Istruzioni per l’uso FASE 2 - Impostazione del telecomando TuneCommand AV 1. Girare il telecomando in modo che i tasti siano rivolti verso il basso. Premere il pulsante di apertura per aprire l’alloggiamento della batteria; quindi tirarlo fuori leggermente fino a quando si blocca (Fig.2).
Seite 70
Ogni volta che si preme un tasto, il dispositivo passa alla funzione successiva. Quando viene utilizzato con iPod video, nano o photo, il TuneCommand AV consente di scorrere tra i video, le fotografie o le presentazioni in modalità wireless! NOTA BENE: •...
Seite 71
Se la batteria è scarica, la spia sul telecomando continua a lampeggiare, cambiando colore: da verde o arancione a rosso. Se ciò si verifica, sostituire le batterie scariche con una batteria dello stesso tipo (CR 2032). Il TuneCommand AV continuerà a funzionare normalmente fino a quando la batteria sarà completamente scarica.
Seite 72
Utilizzo della clip multiuso La clip consente di portare il telecomando intorno alla cintura o intorno al collo utilizzando il cordoncino. Non farla scorrere CHIUSURA A SCATTO Come agganciare la clip multiuso al telecomando Come agganciarla alla Come effettuare l’aggancio cintura Utilizzo della clip multiuso | 08...
- Selezionare un brano sull’iPod e premere su “PLAY”. - Verificare che il cavo audio sia collegato correttamente alla base dock del TuneCommand AV e all’impianto stereo / home cinema. - Se collegato a un impianto stereo, assicurarsi che il canale audio di entrata dell’impianto stereo sia impostato correttamente.
Seite 74
Specifiche Raggio di copertura: Fino a 35 metri Metodo di trasmissione Radiofrequenza Frequenza: 2.44 GHz Batteria del telecomando: CR 2032 3V Dimensioni del telecomando: 8,9 cm x 3,8 cm x 1,3 cm (senza la clip da cintura; profondità massima con la clip: 1,9 cm) Peso del telecomando (batteria inclusa): 22,6 g Dimensioni della base dock: 8,9 cm x 8,9 cm x 2,5 cm Peso della base dock: 96,4 g...
Seite 75
Informazioni Dichiarazione FCC DICHIARAZIONE DI CONFORMITÀ CON LE LEGGI FCC PER LA COMPATIBILITÀ ELETTROMAGNETICA Belkin Corporation, con sede al 501 West Walnut Street, Compton, CA 90220, dichiara sotto la propria piena responsabilità che il prodotto, F8Z065ea cui questa dichiarazione fa riferimento, Questa apparecchiatura è...
Condizioni non coperte dalla garanzia Tutte le garanzie di cui sopra saranno rese nulle qualora il prodotto Belkin non fosse fornito alla Belkin Corporation per essere sottoposto alle necessarie verifiche dietro espressa richiesta di Belkin e a spese del cliente, oppure nel caso la Belkin Corporation dovesse stabilire che il prodotto non è...
Seite 77
Garanzia di 3 anni sul prodotto offerta da Belkin Corporation 2. Il rappresentante del Servizio Clienti Belkin vi spiegherà come inviare la ricevuta e il prodotto Belkin e come procedere con il reclamo. Belkin Corporation si riserva il diritto di riesaminare il prodotto Belkin danneggiato. Tutte le spese di spedizione per il prodotto Belkin restituito alla Belkin Corporation sono a carico dell’acquirente.
