Connecting it all together
HLS energisers include internal 12v batteries and are ready to operate out of the packaging
although we do recommend charging the energiser for 12 hours prior to use. Please see
section on charging the battery.
Lead connection
Unscrew the terminals enough to slide in the fork terminals on the earth and fence leads.
Securely tighten.
9
Fence connection
Connect the lead with the red croc
clip to the fence (from red terminal)
& the green croc clip (from the green
terminal) to the ground rod. We
recommend a minimum of one ground
rod driven approx. one metre into
the ground. If possible, position the
energiser with the panel facing south
and with a clear line of sight avoiding
obstructions such as tree cover.
10
9
10
