Seite 4
f r a n c a i s IDENTIFICATION DES COMMANDES LED DISPLAY MARCHE (diode blanche)/ ECO(diode rouge) VOL - Diminution du volume VOL + Augmentation du volume Active et désactive la coupure du son Selection de la source BLUETOOTH - WIFI (WiFi/Ethernet) - RCA SOURCES ANALOG 1 - RCA ANALOG 2 - OPTIQUE Position du patch NFC...
IDENTIFICATION DES COMMANDES MARCHE / ECO VOL - Diminution du volume VOL + Augmentation du volume Activation et désactivation de la coupure du son Titre précédent de l'album en cours de lecture Titre suivant de l'album en cours de lecture Pause/Lecture Selection de la source FONCTIONS...
égale à 6,4 ohms pour obtenir 2 x 50 W ou 4 x 25 W RMS. Choisir cette position pour les modèles Cabasse de la gamme Archipel et pour Antigua IW. Connecter le câble d'alimentation au STREAM AMP puis au secteur et basculer l'interrupteur marche/arrêt sur "on".
Seite 7
Paramétrage des sorties enceintes. Sélectionner une des 4 options par appuis successifs sur la touche après la première mise en route du Stream Amp: - 1 paire d’enceintes en STEREO (réglage par défaut). Les diodes SP1, SP2, STEREO sont allumées. - 2 paires d’enceintes en STEREO.
Seite 8
DLNA inclus dans STREAM AMP sont alors listés dans l'application Stream Audio Control et peuvent être lus par tous les lecteurs Cabasse Stream connectés au même réseau. La prise USB de STREAM AMP est pourvue d'une alimentation de 1 ampère pour...
Le STREAM AMP est configuré en mode ouvert pour les connexions Bluetooth. il suffit donc, dans le menu de l'appareil à connecter, de sélectionner "Cabasse STREAM AMP" dans la liste des appareils Bluetooth disponibles. Sélectionner si nécessaire la source Bluetooth en pressant le bouton de la télécommande...
Seite 10
f r a n c a i s CONNEXION FILAIRE (LAN) AU RESEAU ETHERNET La liaison filaire Ethernet garantit un débit de transfert optimum et constant dans tout environnement. Utilisez la si le fonctionnement en mode Wi-Fi présente des coupures ou arrêts intempestifs de la musique, signes d’un réseau Wi-Fi saturé...
Seite 11
Une fois la connexion établie, ouvrir l’application Cabasse et choisir: "configurer le réseau Wi-Fi pour ce lecteur". Suivre pas à pas les instructions d'installation. Note : vous pouvez lancer l'application Cabasse dès la fin de la phase b), et continuer le processus de connexion, l'assistant de configuration apparaissant automatiquement pour la première utilisa- tion.
Vous venez d’acheter un produit Cabasse et nous vous remercions de votre confiance. Dans le but d’optimiser au maximum votre installa- tion, nous vous recommandons de lire attentivement cette notice. INSTRUCTIONS DE SECURITE Explication des symboles vez, adressez-vous à...
Pièces détachées - Vérifications - Si la réparation a Après toute intervention sur nécessité l’utilisation de pièces détachées, l’appareil, demandez au technicien d’effectuer assurez-vous que le technicien a bien utilisé des tests afin de garantir que l’appareil fonc- les références préconisées par le fabricant ou tionne en toute sécurité.
f r a n c a i s DÉBALLAGE BRANCHEMENT DU SYSTEME Ouvrir largement le carton puis sortez un à un Connecter le cordon secteur au STREAM les différents éléments. Si l’un des éléments AMP, le brancher au secteur et basculer l'in- du carton vous semble endommagé, ne pas terrupteur marche/arrêt sur "on".
toUCHEs DE CoMManDEs (stream amp et télécommande) 1 Activer/désactiver le mode ECO 2 3 4 contrôles + et - , marche/arrêt du volume. 5 6 Wifi : retour et avance rapide Bluetooth : titre précédent / suivant de l'album ou de la playlist en cours. 7 Musique: lecture et pause en Bluetooth et wifi.
Seite 16
- Activer si ce n’est déjà fait la fonction Bluetooth dans le menu paramètres de la tablette en ap- puyant sur le pavé OFF-ON - Dans la liste des appareils disponibles, cliquer sur Cabasse « STREAM AMP ». Si le STREAM AMP n'est pas connecté en Bluetooth à un autre appareil, la connection à la tablette suit automatiquement l'appairage.
Seite 17
ConnECtIon BlUEtootH aVEC Un oRDInatEUR aPPlE 1) ACTIVATION DE LA LIAISON BLUETOOTH STREAM AMP apparait dans la liste des Connecter le STREAM AMP au secteur. appareils, sélectionner le puis cliquer sur Si le STREAM AMP est déjà sous tension, « Continuer » interrompre si elle existe toute liaison Bluetooth active entre le STREAM AMP et un autre appareil.
Seite 18
f r a n c a i s 2) SÉLECTION DU PÉRIPHÉRIQUE DE SORTIE AUDIO Pour écouter vos musiques avec votre Mac, vous devrez sélectionner votre STREAM AMP Sélectionner l’onglet "Sortie" puis la ligne en tant que périphérique de sortie audio dans "STREAM AMP stereo".
Seite 19
2 - Connecter au réseau wifi la tablette ou le smartphone que vous utiliserez avec l’application StreamCONTROL. 3 - Télécharger gratuitement l'application Cabasse Stream Audio Control sur Playstore pour les appareils Android, sur l'App Store pour les appareils Apple. Installer l’application StreamCONTROL sur le smartphone ou la tablette.
f r a n c a i s MARQUAGE DEEE Informations sur les piles et accumu- lateurs présents dans l’équipement Traitement des appareils électriques (Applicable dans les pays de l’Union et électroniques en fin de vie (appli- européenne). cable dans les pays de l’Union euro- péenne).
MISE A JOUR AUTOMATIQUE Consultez nos réponses aux questions souvent Les mises à jour du logiciel de STREAM AMP posées sur www.cabasse.com, à la page FAQ sont automatiques. STREAM. La durée de mise à jour est variable et peut durer jusqu'à...
Seite 22
STREAM AMP 100 - 1 entrée DLNA : soit filaire avec prise RJ45 soit WiFi Entrées - 1 entrée Bluetooth APTX digitales - 1 entrée optique S/PDIF - 1 entrée USB Entrées analogiques 2 RCA stéréo...
Seite 23
Amplification 2 x 50 W RMS/4-8 ohms 4 x 25 W RMS/4-8 ohms Taux de distorsion plus Wifi : < 0,1% bruit Bluetooth : < 0,1% (THD+N sur la bande Analogique : < 0,1% 20-20 000 Hz pour une puissance de Optique <...
e n g l i s h IDENTIFYING CONTROLS LED DISPLAY ON (white LED) / ECO (red LED) VOL - Volume DOWN VOL + Volume UP Mute on/off Source selection BLUETOOTH - WIFI (WLAN/LAN) - RCA ANA- SOURCES LOG 1 - RCA ANALOG 2 - OPTICAL Position of the NFC patch 26 26...
Seite 27
IDENTIFYING CONTROLS ON / ECO VOL - Volume DOWN VOL + Volume UP Mute on/off Previous title of the played album Next title of the played album Pause/Play Source selection FEaTuRES Bluetooth WIFI/ETHERNET WIFI direct to connection via internet router smartphone/tablet Loss less audio playback access to any audio from...
Seite 28
4 x 25 W RMS with minimum impedance value above (or equal to) 6.4 ohms, for instance Cabasse Antigua IW or Archipel models. Connect the power cable to the STREAM AMP, plug it to the mains and position the POWER ON/OFF switch on "ON".
Seite 29
Settings of the loudspeakers outputs Press to select between the 4 possible set-ups: - 1 STEREO pair of loudspeakers (default mode). The SP1, SP2, STEREO LEDs are on. - 2 STEREO pairs of loudspeakers. The SP1, SP2, SP3, SP4 and STEREO LEDs are on. - 2 loudspeakers playing MONO.
STREAM AMP, will be listed in the Stream Audio Control apps and can be played by any Cabasse Stream player connected to the same domestic network. The USB input is fitted with a 1 ampere power output enabling the use of a portable hard drive with no need...
BLuETOOTH CONNECTION STREAM AMP is set in on open mode for Bluetooth connections. Select "Cabasse STREAM AMP" in the available Bluetooth devices list. Select the BLUETOOTH input with key on the Stream remote or on the Stream Amp. If a Bluetooth source is already connected to STREAM AMP, disconnect this item before selecting a new one.
Seite 32
Internet sources such as Vtuner, Deezer and the STREAM AMP firmware updates are not available. Activate the STREAM AMP, Install and open the Cabasse app on your tablet/smartphone and select "Use this device in standalone mode" instead of "configure this audio device". Follow the instructions...
Seite 33
Launch the Cabasse Stream app. Once connected to STREAM AMP, select STREAM AMP in the available wifi networks list and follow the set-up instructions. Note: from phase b), you may open the Cabasse application and follow the instructions of the online guide, which is launched automatically when connecting for the first time.
Thank you very much for choosing Cabasse speakers. Please read these instructions carefully before setting up your speakers. IMPORTANT SAFETY INSTRUCTIONS Explanation of graphical symbols labels on the product. If you are not sure of the...
Seite 35
Spare parts - Checks - If spare parts are needed to After any servicing of the device, ask repair the device, make sure that the techni- the technician to perform appropriate testing cian followed the manufacturer’s recommen- to make sure that the device works safely. dations or that the replacing parts feature the same specifications as the original ones.
STREAM AMP keypad. The wifi and Bluetooth in the original packing and contact your functions remain available. The audio section authorised Cabasse dealer immediately. We of STREAM AMP is no longer powered. suggest you to retain the packing for future use.
Seite 37
uSE OF STREaM aMP WITH CONTROL KEYS aND THE STREaM REMOTE CONTROL 1 ECO / ON mode selection 2 3 4 VOL "+" and "-", Mute keys 5 and 6 wifi: reverse and forward scan- ning Bluetooth: previous and next title of the played album or playlist.
Seite 38
- If not already done, activate the Bluetooth Function in the « Settings » menu of your tablet by pressing on the ON-OFF switch. - Press “Scan for devices” and select « Cabasse STREAM AMP » among the available devices. STREAM AMP is now paired with the tablet and connected to STREAM AMP is no other Blue- tooth connection to STREAM AMP is active.
Seite 39
BLUETOOTH CONNECTION TO AN APPLE COMPUTER 1) BLuETOOTH MODE aCTIVaTION Connect the STREAM AMP to mains to power Select « STREAM AMP » in the list of items it on. If STREAM AMP is already on, stop and click on “Continue” any running Bluetooth connection between STREAM AMP and any other item.
Seite 40
e n g l i s h 2) SELECTION OF THE auDIO OuTPuT DEVICE To enjoy the musics stored on you Mac with Select "STREAM AMP Stereo" in the « Out- STREAM AMP, set up STREAM AMP as your put » tab. The line "STREAM AMP" stands for audio output device in the “System Prefe- the hands free set up to be used only with a rences”...
Seite 41
USE OF STREAM AMP wITH StreamCONTROL APP 1 - Switch ON the POWER button on the back of the STREAM AMP. STREAM AMP IS ready to play when the LED 1 illuminates red (stand-by mode), press key 1 on the front board of STREAM AMP or on the remote control to get STREAM AMP on.
To get the list of Cabasse retailers, contact us could otherwise be caused by inappropriate or consult our web site www.cabasse.com.
Seite 43
STREaM aMP 100 - 1 DLNA input: either wired with RJ45 cable or Wifi Digital inputs - 1 Bluetooth APTX input - 1S/PDIF optical - 1 USB input analogue input 2 stereo RCA NFC patch in the center of the front panel...
Seite 44
e n g l i s h FEaTuRES Bluetooth WIFI/ETHERNET WIFI direct to connection via internet router smartphone/ tablet Loss less audio playback access to any audio from WLaN network (desktop...) Multi-room Tracks playback from smartphone/tablet Playback smart- phone/tablet a audio applications (youtube…) Playback from uSB...
FCC STaTEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
d e u t s c h ERKLÄRUNG DER BEDIENELEMENTE LED DISPLAY EIN (LED weiss) /ECO (LED rot) VOL - Lautstärke verringern VOL + Lautstärke erhöhen Stummschaltung Ein/Aus Quellenwahl WIFI (WLAN/LAN) - BLUETOOTH QUELLE RCA ANALOG 1 - RCA ANALOG 2 - DIGITAL OPTISCH Position des NFC-Patch 48 48...
Seite 49
ERKLÄRUNG DER BEDIENELEMENTE EIN / ECO VOL - Lautstärke VERRINGERN VOL + Lautstärke ERHÖHEN Stummschaltung Ein/Aus Vorheriger Titel des gerade gespielten Albums Nächster Titel des gerade gespielten Albums Pause/Play Quellenwahl FUNKTIoNEN Bluetooth WIFI/ETHERNET WIFI direkt to Verbindung via Internet Router Smartphone/Tablet Loss less audio Abspielen Zugriff alle Audio Medium...
Seite 50
d e u t s c h SCHNELLEINSTIEG Platzieren Sie das STREAM AMP in der Nähe einer Steckdose. Achten Sie darauf, dass oberhalb, unterhalb und hinten, für die optimale Wirkung der Bluetooth-und WLAN- Antennen und eine ausreichende Belüftung genug Freiraum gibt. Verbinden Sie 2 oder 4 Lautsprechern am Stream Amp.
Seite 51
Auswahl des Lautsprecher Ausgänge Konfiguration. Betätigen Sie die Taste um die Konfiguration zu ändern: - 1 STEREO Paar von Lautsprechern (Fabrikeinstellungen). Die SP1, SP2, STEREO LED kontinuierlich leuchten. - 2 STEREO Paar von Lautsprechern. Die SP1, SP2, SP3, SP4 und STEREO LED kontinuierlich leuchten. - 2 Lautsprechern mit MONO Signal.
Dateien werden – soweit ihr Format kompatibel mit dem im STREAM AMP integrierten DLNA-Server ist – in den StreamCONTROL Apps angezeigt und können von jedem Gerät der Cabasse- Stream-Reihe, das mit dem gleichen Netzwerk verbunden ist, wiedergegeben werden. Der USB-Anschluss ist mit einem Stromversorgungs-Ausgang mit 1 Ampere Stromlieferfähigkeit ausgestattet, so dass auch portable Festplatten ohne externes Netzteil...
Wiedergabe von Internet-Quellen wie vTuner oder Deezer sowie das Firmware-Update des STREAM AMP sind nicht möglich. Aktivieren Sie das STREAM AMP, installieren und starten Sie die Cabasse-App auf Ihrem Tablet/ Smartphone und wählen Sie „Use this device in standalone-mode“ statt „Configure this audio...
Wiedergabe von Internet-Quellen wie vTuner oder Deezer sowie das Firmware-Update des STREAM AMP sind nicht möglich. Aktivieren Sie das STREAM AMP, installieren und starten Sie die Cabasse-App auf Ihrem Tablet/ Smartphone und wählen Sie „Use this device in standalone-mode“ statt „Configure this audio...
Starten Sie die Stream-App. Wählen Sie "configure this audio device" und folgen Sie den weiteren Anweisungen. Anmerkung: von Phase b) an können Sie die Cabasse-App starten und den Online-Anweisungen folgen, die beim ersten Herstellen einer Verbindung automatisch angezeigt werden.
Wir bedanken uns für den Kauf eines Lautsprechers von Cabasse. Lesen Sie bitte die Betriebsanleitung durch, um sich mit dem Gerät vertraut zu machen. Bewahren Sie die Anleitung auf, um auch zukünftig nachschlagen zu können.
Seite 57
Netzanschluss - Fremdkörper oder Flüssigkeiten Das Gerät darf nur Geräteinnere gelangt sind. mit dem Stromnetz verbunden werden, das Gerät hingefallen ist und/oder das wenn die Netzspannung der Steckdose, an Gehäuse sichtbare Schäden aufweist. der das Gerät betrieben werden soll, der das Gerät nass geworden ist (z.B.
Fall sämtliche Komponenten in der Originalverpackung wieder ein und ANMERKUNG: WLAN-Modus informieren Sie unverzüglich Ihren Cabasse- STREAM AMP ist verfügbar, wenn die PWR- Händler. LED etwa 40 Sekunden nach Einschalten des STREAM AMP von rot auf grün wechselt.
BENUTZUNG DES STREAM AMP MIT DER FERNBEDIENUNG 1 EIN / ECO 2 3 4 VOL -, VOL +, Stummschaltung 5 und 6 WLAN: abwärts und aufwärts scannen Bluetooth: vorheriger Titel, nächster Titel 7 Pause/Play (WLAN und Bluetooth) 8 Quellenwahl: Betätigen Sie diese Taste, um eine der angeschlossenen Quellen zu aktivieren: Bluetooth (LED 9 ist blau), WLAN (LED 9 leuchtet orange) oder ana-...
- Wenn noch nicht erfolgt, aktivieren Sie im Einstellungs-Menü Ihres Smartphones/Tablets Bluetooth. - Betätigen Sie „Geräte suchen“ und wählen Sie „Cabasse STREAM AMP“ aus den verfügbaren Geräten Das STREAM AMP ist nun mit dem Smartphone/Tablet gekoppelt, wenn keine andere Bluetooth- Verbindung aktiv war.
SOFORTIGE NFC-VERBINDUNG MIT EINEM NFC-SMARTPHONE Erklärung auf Seite 53. BLUETOOTH-VERBINDUNG MIT EINEM APPLE-COMPUTER 1) AKTIVIEREN DES BLUETooTH-MoDUS Wählen Sie „STREAM AMP Verbinden“ Schalten Sie das STREAM AMP ein. Beenden Sie eine etwaige Bluetooth-Verbindung mit ei- nem anderen Gerät. Aktivieren Sie Bluetooth auf Ihrem Apple-Com- puter: Wählen Sie im „Apple“-Menü...
d e u t s c h 2) AUSWAHL DES AUDIo-AUSGABEGERÄTS Zur Wiedergabe der auf Ihrem Mac gespei- Wählen Sie unter „Ausgang“ „STREAM AMP cherten Musik mit dem STREAM AMP wäh- Stereo“. Die Zeile „STREAM AMP “ dient len Sie bitte im „Systemeinstellungen“-Menü nur zur Verwendung der Freisprech-Fun- „STREAM AMP “...
Seite 63
Version allemande de USE OF STREAM AMP wITH StreamCONTROL APP 1 - Switch ON the POWER button on the back of the STREAM AMP. STREAM AMP IS ready to play when the LED 1 illuminates red (stand-by mode), press key 1 on the front board of STREAM AMP or on the remote control to get STREAM AMP on.
d e u t s c h nationalen Gesetzgebung dafür zuständigen BATTERIEWECHSEL BEI DER Sammelstellen. Mit der korrekten Entsorgung FERNBEDIENUNG dieser Produkte helfen Sie dabei, wertvolle Heben Sie die Klammer auf der Rückseite Ressourcen zu schonen und vermeiden mögliche des Gebers an und entfernen Sie den negative Auswirkungen Gesundheit...
Geräte-Öffnungen fließen könnten. Bitte benutzen Sie auch keine Lösungsmittel, KUNDENDIENST Chemikalien oder Reinigungsmittel, die Alkohol, Cabasse verfügt über ein Netz zugelassener Salmiakgeist oder Scheuermittel enthalten. Händler, dessen Kundendienst Ihnen voll Den Stoffbezug Ihrer Satelliten können Sie, falls und ganz zur Verfügung steht. Wenn Sie die notwendig, mit einem Staubsauger reinigen.
Seite 66
STREAM AMP 100 - 1 DLNA-Eingang, entweder über kabelgebundenes Ethernet oder WLAN Digitaleingänge - 1 Bluetooth-APTX-Eingang - 1 S/PDIF-Eingang optisch - 1 USB-Eingang Analogeingang 2 RCA strereo NFC-Patch im Zentrum des Frontgrills Sofortige Bluetooth-Verbindung...
Seite 67
Verstärkerleistungen 2 x 50 W RMS / 4-8 Ohm 4 x 25 W RMS / 4-8 Ohm WLAN : < 0,1% Verzerrungen und Rauschen Bluetooth : < 0,1% (THD+N von 20 bis 20.000Hz Bandbreite Analog : < 0,1% und Verstärkerleistung oberhalb 100mW) Optisch <...
Seite 71
控制键标识 开/ECO节能 音量 - 音量下降 音量 + 音量上升 静音 开/关 所播放专辑的上一 首曲目 所播放专辑的下一 首曲目 播放/暂停 信号源选择 Features Bluetooth WIFI/etHerNet WIFI direct to connection via internet router smartphone/tablet Loss less audio playback access to any audio from WLaN network (desktop...) Multi-room tracks playback from smartphone/tablet Playback smartphone/...
Seite 73
VersION CHINOIse De settings of the loudspeakers outputs Press to select between the 4 possible set-ups: - 1 STEREO pair of loudspeakers (default mode). The SP1, SP2, STEREO LEDs are on. - 2 STEREO pairs of loudspeakers. The SP1, SP2, SP3, SP4 and STEREO LEDs are on. - 2 loudspeakers playing MONO.
Seite 84
中文 Version chinoise de USE Of StrEam amP with StreamCONtrOL aPP 1 - Switch ON the POWER button on the back of the STREAM AMP. STREAM AMP IS ready to play when the LED 1 illuminates red (stand-by mode), press key 1 on the front board of STREAM AMP or on the remote control to get STREAM AMP on.
Seite 87
放大部分 高音:10瓦;中音:10瓦;低音:20瓦×2 失真率及噪音: 无线Wifi状态:小于0.1% (总谐波失真+噪音,20到20 蓝牙状态:小于0.1% kHz带宽下,100mW及更高 模拟输入状态:小于0.1% 功率输出 ) in Chinese: 91 x 218 x 190 mm 外形尺寸(高×宽×深) 3.58 x 8.58 x 7.48 in 重量 1.9公斤(4.2磅) Features Bluetooth WIFI/etHerNet WIFI direct to connection via internet router smartphone/ tablet Loss less audio playback access to any audio from WLaN network...
Seite 88
Cabasse SA - 210, rue René Descartes - BP 10 - 29280 Plouzané Tel +33 (0)2 98 05 88 88 - Fax +33 (0)2 98 05 88 99 www.cabasse.com...
