• Eight balanced audio inputs and eight balanced audio outputs, each utilizing
18-bit converters to transfer audio data to and from the MediaMatrix system.
• Eight analog control inputs that may be used to control a device in a
MediaMatrix view.
• Eight digital control outputs that may be used to drive external TTL logic level
devices.
• A digital interface, 9-pin D-type connector.
®
The MediaMatrix MM-8800 series Break-Out-Box (BoB) provides the means of interconnection between the
MediaMatrix MainFrame, MiniFrame or X-Frame, and other components of the audio system.

FRONT PANEL

POWER LED (1)
Illuminates when AC power is being supplied to the unit.
