Ravcore LANCE Installationsanleitung Seite 5

EN
• Controller will go to sleeping status after 10 minutes connec-
tion and without any operation
• Low power alarm: Controller LEDs flashing at 0.5Hz 1/4duty
states low power when it connects with console.Controller
shut off automatically when super low power
• Low power: 3.3V± 0.1V, LED flashing frequency:0.5Hz 1/4duyt
• Super low power: 3.1V± 0.1V, controller shut off
Motor: Double Vibration
Working current/voltage:
• working voltage: 3,7V ;
• maximum static current: 10mA≤
• maximum vibration current: 120mA≤
Design: Ergonomic
Direction buttons up / donw / left/right: Control the direction
of the role
Action buttons 1 2 3 4 5 6R 7LT 8RT 11 12: Action command
Select button: Two player/Single play; Inventory Tabs/Items
Start button: Start games/Pause
Left joystick: To control role's direction when analog mode
(Press down the joystick, it can set the button function)
Right joystick: Adjust the view
HOME: Home function
TURBO: 12345678 button,any button can be set with turbo
function
CLEAR: Clear the TURBO setting
5
