Solid State Logic Nucleus Installations-Handbuch Seite 8

Connect
† The Pre-amp Output is internally wired in parallel with the Insert Send.
‡ The External and iJack Inputs are internally summed together.
4
Power Switch
Mains Inlet
Pre-amp 2 Pre-amp 1
Output † Output †
Insert † Insert †
Microphone Microphone
and DI Inputs and DI Inputs
External Input ‡
Monitor Output
