Exploded View Arc Mini R2
1. Front fan filter
2. Fan controller switch
3. 2 x USB 3.0
4. Removable/rotatable upper HDD cage
5. Removable lower HDD cage
6. HDD tray with silicone anti-vibration grommets
7. Removable top panel with dust filter
8. Top panel radiator mounting
9. SSD mounts behind M/B plate
10. Window side panel
