Technical Specifications; Technical Assistance - Garantee - Extel SUNLIGHT DETECT Installations- Und Bedienungsanleitung

Warning:

TECHNICAL SPECIFICATIoNS

4
Photovoltaic solar panel
- Rated voltage: 6V
- Maximum power: 1,1W
- Operating temperature: -40°, +85°C
- Dimensions: 200 x 180 x 15 mm
- Weight: 0,405 kg
LED light
- Rated voltage: 6V
- Maximum power: 2,5W
- Operating temperature: -20°, +50°C
- Luminous flux: 160 to 170 lm
MAINTENANCE
5
It is advisable to clean the panel regularly for optimum recharge capacity. The guarantee is void if parts have been
dismantled. Clean the outside with a soft dry cloth only.
Warning: Do not use any carboxylic acid or alcohol-based or other similar product or solvent. In addition to the
risk of damage to your device, fumes are also dangerous to health and are explosive.
For cleaning purposes do not use any tool that may act as a voltage conductor (e.g. metal brush or sharp tool) or
that could potentially scratch the glass.

TECHNICAL ASSISTANCE - GArANTEE

6
Fault
Detection does not work
or is possible only at a
short distance
The light comes on
unexpectedly
If necessary, our technical website is at your disposal www.cfi-extel.com
GUARANTEE CONDITIONS :
The guarantee does not cover: the consumables (batteries, etc.) and the damages caused by: misuse,
improper installation, external intervention, deterioration by mechanical or electrical shock,
The sales slip or the invoice is required as proof of purchase date.
GB
- Charge the lamp for 14 hours before using it for the first time.
- If the ambient temperature is high, the detection distance will be reduced
- This device operates correctly in total darkness
Cause
-Too much light
- Battery charge too low
animals, windy area, heat
source, etc.
HoTLINE : 0892-35-00-69 (0,337€ttc/min)
Last version of the dowloadable manual in color on :
This device is guaranteed for labour and parts in our premises.
fall or atmospheric phenomenon.
CFI EXTEL SUNLIGHT DETECT - 11/2010 - V1
IR Detector
- Detection angle: 120°
- Outdistance detection: 5 m
- Operating temperature: -20°, +50°C
Solution
- The system will work when it gets darker.
- Charge the lamp for 14 hours before using it
for the first time.
Modify the direction in which the detector is
pointing
www.cfi-extel.com
