Equipment and Accessories Supplied

1. PMR-122TX
1) Radio (1)
2) Instruction Manual (1)
Optional Accessories : 1) AC Wall Charger
2. PMR-122TX-2CH (Bonus pack)
1) Radio (2)
2) Instruction Manual (1)
3) Rechargeable Batteries (2 packs)
4) Dual Desk-Top Charger (1)

Powering the transceiver

Your PMR-122TX Radio transceiver operates on four AAA
batteries. Alkaline batteries will provide slightly better performance
than rechargeable batteries. When using rechargeable batteries,
battery charging time istypically12-15 hours.

Installing the batteries

Battery installation is made more convenient when the belt clip is
either rotated left or right to the horizontal position, or is removed.
simply rotate the clip in either direction to the horizontal position.
Be careful not to use excessive force. To remove the clip, press
down on the spring release tab and pull the clip straight out from
the radio body.
CLIP SPRING
RELEASE TAB
BELT CLIP
BATTERY
COVER
1. Using thumb, press down on battery cover at arrow and slide
cover down.
2. Then lift cover at bottom to open. Remove cover.
3. Insert four AAA batteries (positive (+) end toward the top
begining at left side and alternating positive terminals as shown).
2) Rechargeable Batteries
5) AC Wall Adaptor (1)
6) Ear bud (2)
7) Leather case (2)
3
COVER
ARROW
POSITIVE
TERMINALS
