CABLE INSTALLATION

Internal Routing
1.
Remote
1. Install the remote on the handlebar. Feed the cable through the remote.
2. Feed the cable through the elbow barrel adjuster.
3. Feed the cable into the housing. Make sure the cable end is on the housing
before you feed the cable through.
4. Push the cable all the way through the housing.
Continue on to the next page
GARNET DROPPER
Cable End Cap
OWNER'S MANUAL & SET UP GUIDE
2.
Elbow Barrel Adjuster
3.
ENGLISH
4.
9
