LIGHT REPLACEMENT

20 W halogen light.
• Extract the lamp from the lamp holder by pulling
gently.
• Replace with another of the same type, making sure
that the two pins are properly inserted in the lamp
holder socket holes.
Lamp Power (W)
28
20
35
50
20
20
16
18
9
11
EN
Lighting
Socket Voltage (V)
E14 220 – 240
G4
GU10
GU10
GU4
GU5.3
G13
G13
60 (lamp)
G23
220-240 (starter)
91 (lamp)
G23
220-240 (starter)
Dimension (mm)
104 x 35
12 33 x 9
230 51 x 50,7
230 51 x 50,7
12 40 x 35
12 46 x 51
95 720 x 26
57 589,8 x 26
167 x 28
235,8 x 28
ILCOS Code
HSGSB/C/UB-28-220/240-E14
HSG/C/UB-20-12-G4
HAGS-35-230-GU10-51/40
HAGS-35-230-GU10-51/20
HRGS-20-12-GU4-35/30
HRGS-20-12-GU5.3-50/10
FD--16/40/1B-E--G13--26/720
FD--18/40/1B--E--G13--26/600
FSD-9/27/1B-I-G23
FSD-11/40/1B-I-G23
