• When cutting rivets, bolt heads or the like with HCE25V
/ HCE25, the tool should be fitted with a splinter guard
to prevent cut-off rivets or bolt heads flying off. A splinter
guard can be ordered as an original accessory (Part No.
375,56).

Maintenance

Check that the shears are not damaged. If they are chip-
ped replace them! The shears will work if they are chipped
but the stress concentration caused by such damage could
mean that the shear will break next time it is used.
Oil the shears and lubricate moving parts with high grade
lubricating grease.
Service
Replacing shears 363-1 / 369 (Fig. 2)
1. Remove the bolt and washer (item A), remove the lever
(item B)
2. Remove the bolt and washer (item C), remove the lock-
ing washer (item D)
3. Remove the circlip and pin (item G), remove the moving
shear (item H)
4. Remove the bolt, nut and guard (item J)
5. Unscrew the fixed shear (item K)
Reassemble in the reverse order. NOTE, lubricate all rub-
bing surfaces with high grade lubricating grease.
Replacing shears HCE25V / HCE25 (Fig. 3)
1. Remove the pins (item A)
2. Remove the shears (item B)
Reassemble in the reverse order.
Warning! The cutting edges must be adjusted so that the
distance is 1-2 mm as per fig. 3 when the piston is pum-
ped towards the stop.
Adjustment of cutting edges HCE25V/HCE25
(Fig. 3)
1. Loosen the locking ring and pin (pos. E) to release the
adjustable cutting edge (pos. F) from the piston.
2. Loosen the locking nut (pos. D) and turn the fixed shank
(pos. C) until the desired distance is achieved.
Reassemble in the reverse order.
