INSTALLATION

1. Before switching on for the first time, carefully remove the packaging material taking care not to
damage the appliance and power cable. Do not use the product if it is damaged in any way.
2. The unit may only be used indoors in dry conditions.
3. The free flow of warm air must be ensured for proper operation, therefore, please select the location
for wall mounting according to Figure 2. Do not locate the appliance directly below a wall outlet.
4. In order to insert the wall studs, drill holes of appropriate size into the wall, at least 180 cm from the
floor, along a horizontal line and 49,3 cm from each other.
5. Insert the studs into the holes then drive the enclosed screws into the studs so that the screw heads
extend approx. 15 mm from the wall surface.
6. Hang the unit's rear panel onto the screw heads at the holes, lower it then move it all the way to the
left. Confirm that the heater is hanging securely on the wall.
7. Plug the unit's standard grounded AC power cable into a grounded wall outlet.
8. Please insert 1 pc CR2025 battery in the remote control. Please pay attention on right polarity. After
this your device is ready to use.
Caution: Risk of electric shock! Do not attempt to disassemble of modify the unit or its
accessories. In case any part is damaged, immediately power off the unit and seek the assistance of
a specialist.
In the event that the power cable should become damaged, it should only be replaced by the
manufacturer, its service facility or similarly qualified personnel.
Meaning of symbol on appliance: Do not cover!
Covering the unit can cause overheating, fire or electric shock!
FEATURES
wall-mountable PTC* fan heater for heating the atmosphere of indoor premises • selectable power output (1000 / 2000W) • operating modes: cold, warm and hot air • built-in thermostat • overheating protection • 8-hour timer • combo
LCD display • remote controller
ASSEMBLY (Figure 1)
1. cold air inlet • 2. heated air outlets • 3. ON/OFF switch, heating stage selector • 4. timer control • 5. IR remote sensor • 6. temperature control • 7. combo LCD display • 8. power cable • 9. mounting points • 10. screws & studs • 11.
ON/OFF switch • 12. heating stage selector • 13. timer control • 14. temperature control
OPERATION
The appliance can be controlled using the remote controller or via the control panel buttons.
After plugging the unit into a power receptacle, it will emit a short beep and the combo LCD display will display the current temperature in °C.
Functions of the button on the unit. The combo LCD display shows an animation corresponding to the current operating mode.
press switched function
no. 1 fan
no. 2 heating, stage I (1000 W)
no. 3 heating, stage II (2000 W)
no. 4 cooling (30 sec), power off
Do not remove power until the appliance stops automatically because doing so will damage it.
The FUNCTION button on the remote control is used to select the desired heating stage or fan only mode.
The + / – buttons on the appliance and the remote control are used to adjust or confirm the reference temperature to be achieved, which the unit shows for 3 seconds after the button is pressed.
The unit's thermostat will turn on heating mode selected in advance when the ambient air temperature falls below the value set. As the set temperature is reached, the heating elements turn off while the fan continues to operate.
The TIMER button on the appliance or the remote controller can be used to set the remaining operating time, in 1-hour increments up to 8 hours. A clock icon on the display indicates activation of the TIMER function. The TIMER setting
will automatically clear when the unit is switched off.
In the event of overheating, the overheating protection function will switch off the unit, for example, when the air inlets and outlets are covered. Power off the unit by unplugging it from the electric outlet. Allow the appliance to cool (for at
least 30 minutes). Check whether the air inlets and outlets are obstructed or not, and clean them if necessary. Switch on the unit again. If the overheating protection activates again, power off the unit by unplugging it from the electric
outlet and contact the service facility.
CLEANING & MAINTENANCE
In order to ensure optimum functioning, the unit may require cleaning at least once a month, depending on the manner of use and degree of contamination.
1. Switch off and power off the unit by unplugging it from the electric outlet prior to cleaning.
2. Allow the appliance to cool (for at least 30 minutes).
3. Use a vacuum cleaner with a brush attachment to clean the air inlet and outlet openings.
4. Use a slightly moistened cloth to clean the unit's exterior. Do not use any aggressive cleaners. Avoid getting water inside of and on the electric components of the appliance.
TROUBLESHOOTING
Cause
the unit does not heat in heating mode
the overheating protection activates frequently
the unit does not respond to the remote controller's signal
DISPOSAL
This symbol of the crossed out wheeled bin – on the product or its packaging – indicates that the product should not be placed in municipal waste.
The appliance should be taken to a waste collection site licensed to collect waste electronic and electric equipment (WEEE) or the local waste management facility.
By doing so, you will protect the environment as well as the health of others and yourself.
For more information about recycling this equipment, please contact your local government, household waste disposal service or shop where you purchased
the equipment.
Battery disposal
Do not dispose of used batteries with normal communal waste. The user is obliged under law to take any used or dead batteries to the local collection facility or point of original purchase.
This allows the environmentally friendly disposal of batteries.
SPECIFICATIONS
power supply: . . . . . . . . . . . 230V / 50 Hz
rated power: . . . . . . . . . . . . 1000 / 2000 W
max. output: . . . . . . . . . . . . 2000 W
IP protection: . . . . . . . . . . . IP20: Not protected from ingress of water.
size of heater:. . . . . . . . . . . 52 x 20 x 12,5 cm
weight: . . . . . . . . . . . . . . . . 2,9 kg
length of power cable: . . . . 1,6 m
sound pressure: . . . . . . . . . 52 dB(A )
* The PTC (Positive Temperature Coefficient) is a ceramic polycrystalline semiconductor doped with barium and titanium. Its true advantage lies in that it possesses no
temperature self-regulation properties so no precautions need to be taken against overheating, in addition to the unit being significantly energy efficient.
Solution
check the section
on overheating protection
check the thermostat setting
clean the appliance
check the remote controller batteries
