1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the VASMON! Please read the manual thoroughly before bringing this device into service. If the
device was damaged in transit, don't install or use it and contact your dealer.
2. Features
• High-resolution video to VGA converter
• Specially designed for computer CRT and LCD monitors
• Multiple input signals: VGA, composite video or S-Video
• Supports PAL and NTSC video systems
• De-interlaced output mode: 800 x 600, 1024 x 768 and 1280 x 1024 @ 60Hz
• Frequency output: 60HZ, 75Hz and 85Hz
• OSD functions: contrast, brightness, colour, tint, features, resolution
3. The LEDs
- CONVERSION LED off: Press
- CONVERSION LED on and OSD off: Press
- CONVERSION LED on and OSD off: Press
- CONVERSION LED on: Press
4. Connection
VASMON
VASMON – HR VIDEO TO VGA CONVERTER
to start conversion mode.
and simultaneously to return to the factory preset values.
to exit the conversion mode.
or to display the main menu.
