6. PROGRAMMING SUMMARY

Adding a macro button
SELECT USING '>'
Make your choice
ADD NEW BUTTON?
Add new button
BUTTON SIZE...
Button size
LARGE (25 X 25MM)
Large (25x25mm)
MEDIUM (25 x 15 MM
Medium (25x15mm)
SMALL (15 X 15MM)
Small (15x15mm)
<MACRO, HOUSE>
Select MACRO
MACRO 1....4
Macro 1...4
TOUCH SCREEN NOW
Touch the screen
STORED
Saved
TOUCH KEY: 1 NOW
Touch button 1
MACRO STORED
Macro saved
TOUCH KEY: 2 NOW
Touch button 2
MACRO STORED
Wait 5 seconds and your macro is saved or...
TOUCH KEY: 3 NOW
touch button 3
MACRO STORED
Wait 5 seconds and your macro is saved or...
TOUCH KEY: 4 NOW
touch button 4
MACRO STORED
Macro saved
Easy Touch Panel 10™
Adding a function button
Make your choice
SELECT USING '>'
ADD NEW BUTTON?
Add new button
BUTTON SIZE... Button size
LARGE (25 X 25MM)
Large (25x25mm)
MEDIUM (25 x 15 MM
Medium (25x15mm)
SMALL (15 X 15MM)
Small (15x15mm)
<MACRO, HOUSE>
Select HOUSE
HOUSE CODE: A....P
House code A...P
SET FUNCTION
Select function
UNIT 1.....16
Unit code 1...16
ALL LIGHTS ON
All lighting on
ALL UNITS OFF
All appliances OFF
DIM UP
Bright
DIM DOWN
Dim
BUTTON:ON
Button ON
BUTTON:OFF
Button OFF
BUTTON:TOGGLE
TOGGLE button
TOUCH SCREEN NOW
Touch the screen
STORED
Saved
