Thank you for choosing Teslacigs!
Please read this manual carefully prior to using.We are not responsible for any intentional
damage or improper use. If you require any additional information or have any questions
about the product or its use, please contact us via www.teslacigs.com.

PRODUCT INTRODUCTION

Invader IV is another product with higher output power launched by Teslacigs following
Invader III. The user can choose to use 18650/20700/21700 batteries and obtain different
power output by adjusting the voltage of the potentiometer. The maximum power output is
280W. The product is equipped with a large LED light at the body, which allows you to
better know the usage of the product. This product is suitable for users who like to use an
atomizer with low resistance and cloud of vapor. It will bring you an unprecedented Vaping
experience.

PRODUCT CONTENTS

- Invader IV X1
-18650 battery tube X2

SPECIFICATIONS

Dimension: 92*60*28mm
:
Material Aluminum alloy

:

Cell Type two hi drain 18650/20700/21700 cells(discharge current should be above 40A)
Weight: 143g
Maximum Output Wattage: 280W
Voltage Adjust: I-V level
Output Voltage Range: 3~8V
Maximum Output Current: 53A
Resistance Range: 0.08Ω-3.0Ω
Input Voltage Range: 6.4V~8.4V
＜
Standby Current: 50uA
USB: 5V/1.5A
LED light Indicator: blue-green-red
Protections: over puffing protection/reverse connection protection/atomizer short
-circuit protection/low voltage alert/overheat protection/overcurrent protection
2.Power Off: Press the fire button 5 times consecutively when the device is powered
on.The LED light will flash 3 times to indicate the device is powered off.
3.Vaping: Press the fire button simultaneously as you vape. Release the fire button when
not vaping.
4.Adjust Voltage: Rotate knob to adjust voltage from I-V(3-8V).
5.Charging: When charging, the LED light will emit light of different colors according to the
battery level. It will be in red color when charging 0%~30%, green when charging
31%~60%, blue when charging 61%~100% and the LED light will be off when charging to
100%.
Battery Level
0-30%
LED Light Color Red
REMARKS
This package does not include cell or charger.
Please choose suitable cell, the cell should be discharged 40A or above.
Please take out the battery from the device when it's not used for a long time.
Please turn off the device when it's not used for a long time.
CAUTIONS
1.Not intended for use by children under 18 years old, pregnant or breastfeeding women, or
anyone at risk of heart disease, depression, or asthma.
2.Keep out of reach of children and pets.
3. Do not attempt to repair the product by yourself as damage or personal injury may occur.
4. Do not leave the product in high temperature or damp conditions, otherwise it may be dam
aged.
5. Do not use this product for other purposes except only for vaping.
6. This product may be hazardous to health and contains nicotine which is addictive.
7. For people with adverse reactions after use of this product, it is recommended to stop using
this device immediately and consult your doctor.
- USB Cable X1
- User Manual X1
01
03
31-60% 61-100% 100%
Green Blue Off
05


07
English
02 English
HOW TO USE?
1.Power On: Insert two 18650/20700/21700 high drain batteries into the device body.
The LED light will flash 5 times to indicate the device is powered on.
Note: 1.Before using, please adjust the wattage to a proper range to match the atomizer you used.
2.This following setting is based on the conditions: all batteries are fully charged and the discharge current
is greater than 40A.
3.With the reduction of electricity during use, the gear used can be slightly higher than the recommended
gear (I-minimum, V-maximum).
4.In case of under-voltage of the batteries, the device will operate at the maximum output power of the
batteries and users can't increase the output power by adjusting the gears.
5.The maximum output power gear V should be used with caution.
Consult the following table for atomizer resistance, and recommended initial settings:
Atomizer Resistance
English 04 English
PROTECTIONS
1.Over Puffing Protection:The device will deactivate after prolonged continuous puffs
of more than 10 seconds.The LED light will flash 8 times, and then the device will enter
stand-by mode.
2. Reverse Connection Protection: If batteries are inserted incorrectly, the device will
not power on and will prevent any damage to the chipset.
3. Low Voltage Alert: When the voltage drops below 6.4V, the LED light will flash 15 ti
mes and the device will power off.
4. Atomizer Short-Circuit Protection: When an atomizer short circuit occurs, the LED
light will flash 5 times rapidly and the device will shift to stand-by mode.
5.Overheat Protection: When chipset temperature exceed 70 Degrees C ,the LED ligh
t will flash 5 times rapidly and the device will shift to stand-by mode.
6.Overcurrent Protection: when the output current is too high,the LED light will flash
5 times rapidly and the device will shift to stand-by mode.
English
06 English
English
English/French/German/Spanish/Dutch/Russian/Italian/中⽂简体
Micro USB Port
Recommended Initial Setting
(Equivalent Wattage)
0.1Ω 1.0~1.6 (80~90W)
0.2Ω 1.8~2.0 (70~80W)
0.3Ω
1.6~2.0 (60~70W)
0.4Ω 2.0~2.2(40~50W)
2.2 (40W)
0.5Ω
3.0~4.2 (30~40W)
1.0Ω
1.5Ω 3.0~4.2 (20~30W)
2.0~3.6 (10~20W)
2.0Ω
Fire Button
LED light
Potentiometer(I-V)
U
V-Max Wattage
280W
200W
150W
120W
100W
60W
40W
30W
