Fitting to a wooden beam
Four screws (P) are supplied together with safety washer's (O) for fi tting the support plate (A) to a
wooden beam. The holes for the screws should not be of greater diameter than the diameter of the
screw. Ensure that the wooden beam is able to support the weight of the moving fan (minimum
25Kg.) (Fig.4)
ASSEMBLY OF THE FAN
IMPORTANT: If you installing more than one fan, ensure that you do not mix the fan blade sets, even
though they are from the same ceiling fan model.
1.- Fit the blades with the angles as shown in fi gure 5
2.- Fit the blades (C) to the motor assembly and support (B) using the screws (D) and the safety
washers (E). Do not forget to use the felt protection washers between the blade and the motor as-
sembly to avoid possible noise. Repeat this process with the remaining blades. (Fig.6)
IMPORTANT: Be careful not to support yourself on the fan blades, as these could then become
unbalanced and cause vibration or shaking of the fan.
3.- Loosen the screws situated in the base of the decorative canopy to allow easier access to the
anchorage point and electrical connectors. Hang the motor and support assembly (B) from the hook
on the support plate (A) (previously fi xed to the ceiling) (Fig.7)
4.- Connect the cables (Fig.8) and position them correctly. The connections and the fi tting point can
be hidden using the decorative canopy. Tighten the two screws in the base of the decorative canopy.
IMPORTANT: Before working on the electrical supply, always remove the fuses or disconnect the
main cut off switch to the mains supply.
OPERATION INSTRUCTIONS
1. – The speed regulator has four positions.
0 .........OFF
1 ......... High speed
2 ......... Medium speed
3 ......... Low speed

MAINTENANCE

1.- Periodic cleaning is the only maintenance required.
2.- Clean the fan using a soft brush or soft cloth to avoid damaging the fi nish.
3.- When carrying out maintenance work, do not use the fan blades as a support as they
could become unbalanced and so increase the vibration of the fan.
4.- Do not use abrasive cleaning agents as these could damage the fi nish of the fan.
5.- Do not use water when cleaning the fan as this could cause damage to the motor and
deform the fan blades.
IMPORTANT: Before carrying out any maintenance work on the fan, ensure that it is discon-
nected from the mains electrical supply.
