Installation; Specification; Package Content; Warranty - Genesis Rx66 Schnellinstallationsanleitung

features
Anti-ghosting function for 19 keys
3-color keys backlight
Gaming software with pro le and macro editor
On-board memory to save the settings
Programmable keys
CHANGE OF BACKLIGHT COLORS
To change the backlight color, press the keys Fn + F1, F2, F3.
BACKLIGHT BRIGHTNESS
To change the brightness of the backlight use the keys
Fn + Num2 or Fn + Num8
PROFILE CHANGE
Press the key [ ] to switch between 5 pro les.

SPECIFICATION

Keyboard size
Keyboard weight
Connector
Number of key
Number of multimedia keys

PACKAGE CONTENT

RX66 professional gaming keyboard
Quick installation guide
SAFeTY information
Use as directed.
Non-authorized repairs or taking the device to pieces make the
warranty void and may cause the product damage.
Avoid to hit or friction with a hard object, otherwise it will lead to
grind surface or other hardware damage.
Do not use the product in low and high temperatures, in strong
magnetic elds and in the damp or dusty atmosphere.
Do not drop, knock, or shake the device. Rough handling can break it.
Slots and openings in the case are provided for ventilation and should
not be obscure. Blocking the vents can cause overheating of the
device.
493 × 212 × 35 mm
925g
USB
120
10/5
requirements
PC or PC compatible device with a USB port
Windows® XP/Vista/7/8/10

InstalLation

Connect your device to the USB port of your computer, it is
necessary to wait about 15 seconds for the rst connection
until the drivers are fully installed.
The keyboard includes software that allows you to set up
advanced features, if you want to use these features, you
need to download and install the software from our
website www.genesis-zone.com.
Open the installation folder and then double-click the
setup.exe le. Follow the installation instructions.
After a successful installation, the software icon appears on
the main bottom panel. Double-clicking the icon opens
the settings interface.
NOTE: 5 macros can be assigned to each of 5 pro les. The
required pro le must be selected before you start
recording.
MACRO RECORDING
To start the recording, press the keys Fn + F4 (the LED indicator
will start ashing to red color), then select one of the G1-G5
keys (the LED will light continuously), then press the key
combination which you want to assign. To stop the recording
and save the macro, press Fn + F4 again (the red LED will go
o ).

warranty

2 years limited manufacturer warranty
general
The safe product, conforming to the EU requirements.
The product is made in accordance with RoHS European
standard.
The WEEE symbol (the crossed-out wheeled bin) using
indicates that this product in not home waste. Appropriate
waste management aids in avoiding consequences which
are harmful for people and environment and result from
dangerous materials used in the device, as well as
improper storage and processing. Segregated household
waste collection aids recycle materials and components of
which the device was made. In order to get detailed
information about recycling this product please contact
your retailer or a local authority.
