Size Torx Torx Plus Phillips
® ®
1 3.2
2 7.4
3 17.6
4
5
5.5
6
7
8
9
10 4.1
15 5.8 7.3
20 9.5 12.1
25 14.3 17.6
27 20.3 26.1
30 28.0 > 30
40 > 30 > 30
50 > 30 > 30
Recommended maximum torques in Nm for interchangeable blades PB 225
88
Conversion to Foot Pound (ft·lbf): value in Nm x 0.738
Pozidriv Socket wr. Hexagon Slot
3.2
7.4
17.6 5.9
14.4 5.7
27.0 10.2
5.2
6.7 > 30 22.6
10.3 > 30
15.0 > 30
20.7
> 30 > 30

Adjusting the value

1. Set the handle to the lowest setting on the range printed using the
max.
hexagon screwdriver supplied. Always adjust the setting in
max.
metric units. If desired, the device may subsequently be calibrated
according to EN ISO 6789.
Please note: We recommend to recalibrate the handle annually and
to check it regularly using a torque meter.
min.
DigiTorque MultiTorque
min.
