NOMENCLATURE
Main Lens
1
2 Additional Lens
LED illumination
3
4 On/O button
Battery compartment
5
/Battery compartment cover

INSERTING THE BATTERIES

Slide open the battery compartment cover (5) in the direction of arrow. Insert
2 pieces of AAA batteries (optional) according to the polarity markings +/- in
the battery compartment. Close the battery compartment cover. Please remove
batteries when magnifi er is not in use for a longer period.
ILLUMINATION
To turn on the LED illumination (3) press the On/O button (4).
SPECIFICATIONS
Main Lens
Additional Lens
Illumination
Material of lens
Material of handle
Power source
Dimensions
Weight
CONTENT
Magnifi er, hard case, cleaning cloth, instruction manual
Magnifi cation 2,5x
Magnifi cation 5x
2 LEDs
Acrylic
ABS plastic "Soft-Touch"
2x AAA batteries
(optional)
230 x 90 x 30 mm
70 g (w/o batteries)
9
Diameter 90 mm
Diameter 20 mm
1
2
3
4
5
