Technical description

2.5.3

Availability of the operating instructions

These operating instructions have to be read and applied by any person
working on the product.
The operating instructions have to be kept at the installation location.
f Hand these operating instructions and all other valid documents (e.g.
accessory manuals) over to the user.
3. Technical description
3.1

Construction

5
Illustr. 1: Construction wireless movement sensor "BWM-C F"
(1) "Teach in" and configuration button (with green LED)
(2)
Test button (with red LED)
(3)
Cover for movement sensor (passive infrared sensor) and one red
LED
(4) Solar cells
(5)
Mounting plate
22
1 2
4
"BWM-C F"
3
