Install and use the DockingStation
• Connect the USB Type-C
cable to the host computer
• Connect your devices to the appropriate interfaces on the dock.
The dock will automatically install some of the required drivers once it is connected to
your notebook's USB Type-C
the driver(s), follow the on-screen instructions to complete the installation.
• Connect your external display to the DockingStation's video port.
Note: Video output capabilities are dependent on the video card and hardware
specifications of your connected host notebook. Certain graphic cards have limited
support, while some monitors will also limit the output resolution.
Configure a display device
Please setup your display settings accordingly to your operating system and
requirements.For detailed information, see the corresponding operation manual and
description of your operating system.
Supported video resolutions, the DockingStation supports:
• Ultra HD resolution via HDMI
• Full HD resolution via VGA if the connected VGA display supports it.
Number of attached
displays
1
1
2 (only mirrored
among each other)
Important:
When connecting the USB Type-C
mouse to be connected to the USB 3.0 Type-A port will not work immediately; it will have
seconds' delay. This problem also occurs in other similar Type-C
Apple original 3 in 1 adapter) when connected with Chromebook
Attention! When plugging in and out a Power Delivery adapter to the Type-C
of the IB-DK4023-CPD, the connected USB devices will get disconnected flashily and then
reconnect in a few seconds, so to prevent possible data loss or corruption,
avoid (dis-)connecting the Power Delivery adapter from AC power while transferring data.
Manual IB-DK4023-CPD
™
port. If you receive a prompt to automatically install
™
®
Video output
configuration
HDMI
®
VGA
HDMI + VGA
®
plug of the IB-DK4023-CPD to a Chromebook
™
if the connected HDMI
Maximum
resolution/monitor
3820x2160p@30 Hz
2560x1600@120Hz
max 2x 1920x1080@60 Hz
(based on VGA resolution)
display supports it.
®
adapter (including
™
.
™
interface
™
, the
™
