Dear customer!
Rodcraft Pneumatic Tools GmbH thanks you for the purchase of one of our products and invites you to reading this user manual.
All necessary information for an adequate use of the purchased equipment is contained herein: it is advisable to read everything from cover to cover and to
observe the references.
Please keep the user manual in good order. The contents of this manual may change without prior notice and without further obligations, so that changes
and improvements can be inserted into already distributed copies.
It is our aim to manufacture products, with which you can work as safe and effi cient as possible. Most important for your safety are your caution and
judgment in handling this product and other tools. These safety precautions contain some of the important sources of danger; however, they cannot cover all
possible risks.
Without prior written permission of the manufacturer copying or translation of any part of this manual is prohibited.
Model
Rivet
[mm]
6703Xi
2.4 – 4.8 **
676703
6718Xi
2.4 - 6.4 **
676718
max. Pressure 6.3 bar (90 psi)
Rivet Diameter (mm)
Nosepiece (marked
with rivet size)
Nozzle
Force /
Weight
Stroke
F
[N] /
[mm]
[kg]
[mm]
1.8 / 2.1
10900 /
1.5
2.5 / 3.2
20
2.5 / 3.2
15200 /
1.9
4.1 / 4.2
26
** = steel: for steel rivets and softer materials
2.4
3.2
2.4
3.2
Jaw for 2.4 - 4.8 mm
NO
RODCRAFT PNEUMATIC TOOLS GmbH
EN
Inner Hose
axbxc
Air Consumption
Diameter Ø
[mm]
[mm]
[l/stroke]
8
310x287x122
8
310x316x136
4.0
4.0
Jaw for 4 - 6.4 mm
Air
Sound
Inlet
LpA
[inch]
[dB(A)]
2.1
1/4" IG
70.0
4.3
1/4" IG
74.2
4.8
4.8
Vibration
[m/s
]
2
< 2.5
< 2.5
6.4
6.4
NO
8
