Tesla R2 Series Specification
General Specification
Power supply unit (PSU) specification compliance
Dimensions (mm)
Life expectancy (MTBF) at maximum output load
Power factor correction (PFC)
Fan type
Operating temperature
Operating humidity
Protected against
Efficiency
Safety approvals
Electromagnetic compatibility (EMC) standard compliance
Hazardous materials
Power Specification
Voltage
AC Input Frequency
Current
3.3V
5V
3.3V and 5V combined
DC Output 12V
-12V
5V Standby (+5Vsb)
Total Power
Fr actal D esi g n
ATX 2.31
150*86* 165
100,000 hours
Active
135mm, sleeve / ball bearing
0-40°C (50°C at 80% load)
10-90%
Over power
Over voltage
Short circuit
80 PLUS® Gold certified
UL, cUL, TÜV
CE, FCC, C-tick
WEEE/RoHS compliant
500W 650W 800W 1000W
90-264V AC
47-63 Hz
10A/5A 15A/ 7.5A
20A
20A
100W
41.5A 54A 66A 80A
0.5A
2.5A
500W 650W 800W 1000W
22
DC Voltage Regulation
Maximum difference between DC output voltage and nominal value under any load,
line and environmental conditions within specification. The following are the maxi-
mum values allowed by Fractal Design quality control; typical values are lower.
ATX Specification
Fractal Design Tesla R2 Series
Ripple and Noise
Peak-to-peak values of periodic or random signals present on the DC rails over a frequency
band of 10Hz to 20Mhz. The following are the maximum values allowed by Fractal Design
quality control; typical values are lower.
3.3V
ATX Specification <50 mV
Fractal Design Tesla R2 Series <40mV
Cable configuration
Connector type
500W
ATX 20+4 pins
ATX12V/EPS12V 4+4 pins
PCI-E 6+2 pins
SATA 5
Peripheral
Floppy
Package contents
Tesla R2 PSU in protective bag
User's Manual (this book)
AC Power cord (localized)
3.3V 5V 12V -12V +5Vsb
<5% <5% <5% <10%
<3% <3% <3% <8%
5V 12V -12V
<50 mV <120 mV <120 mV <50 mV
<40mV <70 mV <60 mV <40mV
Quantity
650W 800W 1000W
1
1
2 4 6
6 7 9
2
1
Velcro cable ties & zip ties
Mounting Screw pack
23
Tesla Seri es
<5%
<3%
+5Vsb
