The AC3 ZoneController enhances the ControlTL capabilities
of your MiniTT1 and FlexTT5 radios by allowing you to
control the flash output power manually from the camera's
position or use E-TTL II.
AC3 Manual Mode: The Power Dial sets the remote
Speedlite power output as shown in the table on the right.
AC3 Auto Mode: The Power Dial sets the Flash Exposure
Compensation (FEC) relative to the E-TTL exposure for that zone.
Manual and Auto modes can be used at same time. Manual
zones will not be calculated as part of the E-TTL exposure.
Zones set to 0 / (OFF) will not trigger.
FEC NOTE: In Auto Mode, Flash Exposure Compensation
(FEC) can be set in more than one place and the values are used
together - all positive and negative FEC values will be combined.
FEC can be set:
• On each zone independently using the AC3 Power Dial
when the zone is set to A (Auto)
• On each remote Speedlite
• Using the camera's FEC control. All AC3 zones set to
A (Auto) will be affected equally.
If the combined FEC adjustments are more or less than your
flash's capabilities, then the flash will operate at maximum
or minimum output accordingly.
* The Power Dial can adjust over a 6 stop range. To achieve the lowest manual power settings
on your Canon Speedlite, like 1/128, you'll need to adjust FEC down accordingly.
Manual Power Settings
AC3 Canon Speedlite
Power Manual Power
Dial = Output =
3 1/1
2.7 1/2 + 0.7
2.3 1/2 + 0.3
2 1/2
1.7 1/4 + 0.7
1.3 1/4 + 0.3
1 1/4
0.7 1/8 + 0.7
0.3 1/8 + 0.3
0 1/8
0.3 1/16 + 0.7
0.7 1/16 + 0.3
1 1/16
1.3
1/32 + 0.7
1.7 1/32 + 0.3
2
1/32
2.3 1/64 + 0.7
2.7
1/64 + 0.3
3 1/64 *
