Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Register this product at www.greenlee.com
Description
The Greenlee Communications 180XL Visual Fault
Locator is used to visually locate loss locations such
as macrobends, bad connectors, and other fiber
discontinuities. Fiber continuity can also be visually
confirmed.
Safety
Safety is essential in the use and maintenance of
Greenlee tools and equipment. This instruction manual
and any markings on the tool provide information for
avoiding hazards and unsafe practices related to the
use of this tool. Observe all of the safety information
provided.
Purpose of this Manual
This manual is intended to familiarize all personnel
with the safe operation and maintenance procedures
for the Greenlee Communications 180XL Visual Fault
Locator.
Keep this manual available to all personnel.
Replacement manuals are available upon request at no
charge at www.greenlee.com.
Package Contents
1 Visual Fault Locator
2 AA batteries
1 Instruction manual
1 Soft carry case
52068675
INSTRUCTION MANUAL
180XL Visual Fault Locator
© 2014 Greenlee Textron Inc.
Important Safety Information
CAUTION
Do not look directly into the output port when the
instrument is ON. Never use a viewing instrument
such as a magnifier or microscope to view the free
end of any optical fiber connected to the 180XL.
The use of viewing on active fibers can focus an
intense laser beam onto the retina of the eye,
resulting in permanent damage or blindness.
Always aim the free end of an active fiber at a non-
reflective surface.
Do not discard this product or throw away!
For recycling information, go to
www.greenlee.com.
All specifications are nominal and may change as design
improvements occur. Greenlee Textron Inc. shall not
be liable for damages resulting from misapplication or
misuse of its products.
KEEP THIS MANUAL
LASER LIGHT
DO NOT STARE INTO BEAM
1 mW max at 640-660 nm
CLASS 2 LASER PRODUCT
EN 10/14
