IRHPS Power supply module for GEKO IRH infrared LED illuminator English - Instructions manual Italiano - Manuale di istruzioni Français - Manuel d’instructions Deutsch - Bedienungslanleitung...
IRHPS Power supply module for GEKO IRH infrared LED illuminator 1 About this manual 3 Safety rules Before installing and using this unit, please read this The manufacturer declines all responsibility manual carefully. Be sure to keep it handy for later for any damage caused by an improper use reference.
4 Identification • This device was designed to be permanently installed on a building or on a suitable structure. 4.1 Product description and type • When installing the device, comply with all the national standards. designation • The electrical system to which the unit is connected must be equipped with a bipolar circuit Power supply module for GEKO IRH infrared LED breaker.
6 Assembling and installing • If you wish to force the illuminator on, short circuit the 2 cables and isolate them with a terminal. • Connect the 2 cables to an external clean contact if Only specialised personnel should be you wish to turn the illuminator on remotely with a allowed to assemble and install the device.
9.1 Electrical Make sure that the power source and connecting cables are suitable for the IRHPS230: IN 230Vac, 50/60Hz, 30W max - OUT 24Vac, power consumption of the system. 1.2A The power supply from the mains is to be connected IRHPS120: IN 120Vac, 50/60,Hz, 30W max - OUT into terminal J1.
IRHPS Modulo alimentatore per illuminatore infrarosso a LED GEKO IRH 1 Informazioni sul presente 3 Norme di sicurezza manuale Il produttore declina ogni responsabilità per eventuali danni derivanti da un Prima di installare e utilizzare questa unità, leggere uso improprio delle apparecchiature attentamente questo manuale.
4 Identificazione • Questo dispositivo è stato progettato per essere installato in maniera permanente su un edificio o su una struttura adeguata. 4.1 Descrizione e designazione • Si devono rispettare le normative nazionali per del prodotto l'installazione del dispositivo. • L’impianto elettrico al quale è collegata l’unità Modulo alimentatore per illuminatore infrarosso a deve essere dotato di un interruttore di protezione LED GEKO IRH.
6 Assemblaggio e • Nel caso si voglia forzare l’accensione dell'illuminatore, cortocircuitare i 2 cavi ed isolarli installazione con un capicorda. • Nel caso si voglia accendere l'illuminatore da L'assemblaggio e l'installazione vanno remoto con contatto pulito, provvedere a collegare eseguiti solo da personale specializzato.
Controllare che le fonti di alimentazione 9.1 Elettrico ed i cavi di collegamento siano in grado di sopportare il consumo del sistema. IRHPS230: IN 230Vac, 50/60Hz, 30W max - OUT 24Vac, 1.2A L’alimentazione proveniente dalla rete elettrica va collegata nel morsetto J1.
IRHPS Module alimentateur pour projecteur infrarouge à LED GEKO IRH 1 À propos de ce mode 3 Normes de securité d’emploi Le producteur décline toute responsabilité pour les dommages éventuels dus à une Avant d’installer et d’utiliser cet appareil, veuillez utilisation non appropriée des appareils lire attentivement ce mode d’emploi.
4 Identification • Cette appareil est conçu pour une installation permanente sur un bâtiment ou une structure adéquate. 4.1 Description et désignation du • Il faut respecter les législations nationales pour produit l'installation du dispositif. • L'installation électrique à laquelle l'unité est Module alimentateur pour projecteur infrarouge à...
6 Assemblage et • Au cas où l'on souhaite forcer l'allumage du projecteur, court-circuiter les 2 câbles et les isoler installation avec une cosse. • Au cas où l'on souhaite allumer le projecteur L’assemblage et l’installation doivent à distance avec un contact sec, effectuer le exclusivement être effectués par un branchement des 2 câbles à...
Procéder exclusivement aux connexions de 9.1 Électrique la base avec l'alimentation sectionnée et le dispositif de sectionnement ouvert. IRHPS230: IN 230Vac, 50/60Hz, 30W max - OUT 24Vac, 1.2A L'alimentation provenant du réseau électrique doit être branchée dans la borne J1.
IRHPS Netzteilmodul für LED-Infrarotscheinwerfer GEKO IRH 1 Allgemeines 3 Sicherheitsnormen Lesen Sie bitte vor dem Installieren und dem Der Hersteller lehnt jede Haftung für Verwenden dieses Gerätes die Bedienungsanleitung eventuelle Schäden ab, die aufgrund sorgfältig durch. Bewahren Sie sie zum späteren unsachgemäßer Anwendung der in diesem Nachschlagen auf.
4 Identifizierung • Die Einrichtung ist für den dauerhaften Einbau in ein Gebäude oder eine andere geeignete Struktur konzipiert. 4.1 Beschreibung und • Die nationalen Vorschriften für die Installation der Bezeichnung des Produktes Einrichtung sind einzuhalten. • Die elektrische Anlage, an die die Einheit Netzteilmodul für LED-Infrarotscheinwerfer GEKO angeschlossen ist, muss mit einem bipolaren IRH.
Seite 17
6 Zusammenbau und • Soll die Einschaltung des Scheinwerfers erzwungen werden, die 2 Kabel kurzschließen und Installation mit einem Kabelschuh isolieren. • Soll der Scheinwerfer ferngesteuert mit einem Zusammenbau und Installation sind potenzialfreien Kontakt eingeschaltet werden, die Fachleuten vorbehalten. 2 Kabel an einen externen potenzialfreien Kontakt anschließen.
(magnetothermisch, bis zu 20A). 9.1 Elektrik Es ist zu prüfen, ob die Versorgungsquellen und die Anschlusskabel für den IRHPS230: IN 230Vac, 50/60Hz, 30W max - OUT 24Vac, Systemverbrauch ausgelegt sind. 1.2A Die vom Stromnetz kommende Versorgung wird an IRHPS120: IN 120Vac, 50/60,Hz, 30W max - OUT die Klemme J1 angeschlossen.
Seite 20
Tel. +44 0113 815 0031 (Orders/Shipping dept.) Email: uksales@videotec.com France Videotec France S.à.r.l. Asia Pacific Videotec (HK) Ltd Voie du Futur, Zac des Portes - 27100 - Val-de-Reuil, France Unit C 24 Floor - Gold King Industrial Building Tel. +33 2 32094900 - Fax +33 2 32094901 35-41, Tai Lin Pai Road - Kwai Chung, NT, Hong Kong Email: info@videotec-france.com...
