Thank you for purchasing this piece of Stuart
equipment. To get the best performance from the
equipment please read these instructions carefully
before use.
For your own safety and that of others
please read and understand the safety
advice given in section 9.0 of this
manual before using the equipment.
If the equipment is not used in the manner
described in this manual the protection provided
might be impaired.

1 General description

CAUTION: Keep fingers clear when
operating door.
The SI19 mini incubator has been specially
designed for accurate temperature controlled life
science applications. The stainless steel chamber
features 4 shelves which are easy to slide in and
out or quick loading and unloading.
The SI30H Hybridisation incubator /shaker
features advanced temperature controlled forced
air circulation with clear bright LED digital
temperature display. The unit comes complete
with a seven bottle rotisserie which rotates on
guided rollers. Rotation speed is variable between
2 and 10 rpm. A platform is fitted to the back of
the incubator which drops forward to form a
rocking shaker with variable speed of 10 to 50
oscillations per minute. A rotisserie for two
1 2
on
1 5
off
rotisserie
Fig 3: Front panel controls
Rotisserie / shaker controls (SI30H only)
1. Rotisserie/shaker ON/OFF button
2. Rotisserie/shaker speed selector dial
3. Motor on indicator
3
motor
4 5
3 0
6
4
6 0
8
2
1 0
5
7 0
shaker
rpm strokes/min
70mm diameter bottles is available as well as a
range of specially designed Pyrex
bottles.

2 Preparation for use

2.1 Remove all packaging and place the
incubator on a level working surface,
ensuring that there is sufficient room above
the instrument to allow the door to be
opened fully.
2.2 Leave the unit to stand for a minimum of 3
hours. This will allow acclimation to the new
ambient temperature.
2.3 Follow the instructions for Electrical
Installation given in section 8 of this manual
and connect the instrument to the electricity
supply.
2.4 Connect the power cable to a suitably
grounded electrical outlet. The correct
operating voltage of the incubator is found
on the product information label on the rear
of the instrument.
2.5 Turn the Mains ON/OFF switch located at the
back of the unit ON.
2.6 The incubator is now ready for use.

3 Temperature setting

(model SI19 & SI30H)
3.1 The incubator temperature controls are
located on the right hand side of the control
panel (number 4 to 7 in figure 3).
4 5
on
press
off to set
Temperature controls (SI19 & SI30H)
4. Temperature on / off button
5. Press to set button
6. LED temperature display
7. Temperature selector dial
® hybridisation
6 7
C
h y b r i d i s a t i o n o v e n / s h a k e r
SI30H
