Technical Speci cations
Battery Capacity 14000 mAh
DC 15V/1A max
Input
iSmart USB Output 1 DC 5V/2.1A max
iSmart USB Output 2 DC 5V/2.1A max
Starting Current 280A
Peak Current 550A
Recharging Time Approx. 4 hours
Operating Temperature -20 ℃ ~ 60 ℃
Net Weight (Battery Pack) 472 g / 16.64 oz
Dimension 16.9 x 8.5 x 3.6 cm / 6.65 x 3.35 x 1.42 in
Battery Level Indicator
The remaining battery level can be seen on the LCD indicator.
Charging the Battery Pack
There are two ways to charge the battery pack:
• Connect the battery pack with any power outlet using a home power adapter and the 15V input port.
Connect the battery pack with the car cigarette lighter using the car charger cable and the 15V input port.
•
Jump Starting Cars
The battery pack can be used to jump start gasoline powered engines with a 12V battery.
• Check the battery level on the LCD indicator and make sure at least 60% power still remains.
Connect the jump cable with the car battery (Red is positive and Black is negative).
•
• Plug the jump cable into the battery pack.
Start the car by turning on the ignition.
•
Disconnect the car battery as soon as the car has started.
•
/ - 4 ℉ ~ 140 ℉
Charging Mobile Devices
Use any of the two USB charging ports to charge mobile devices, such as smartphones and tablets.
Connect the battery pack with your mobile device using the included USB cable.
•
• Turn the battery pack's power on to start charging.
Note:
When connected with a mobile device, the LCD screen will show "OUT 5V 2.1", indicating that the USB
output is working normally. Power will automatically cut off after 30 seconds if no devices are connected.
LED Flashlight
Press and hold the flashlight button to cycle through ON, SOS (slow flash), Warning (quick flash), and OFF.
Jumper Cable
This jumper cable is for RAVPower RP-PB048 Car Jump Starter Battery only.
Function Uses
Short Circuit Connect with starter battery.
Protection If the cable is short circuited,
Low-voltage
If starting on low voltage,
protection
When car is started but the
Reverse-charging
jumper cable is not disconnected
protection
from car battery,
Reverse-polarity Incorrect polarity connection
protection when connecting with car battery,
High-temperature If using continuously to jump
protection start cars,
Notes
No damage, no fire. The red LED will flash rapidly.
No current output from the cable.
Battery voltage ≤ 10.8V or Battery level is less than
20%, green LED will flash rapidly. No current
output from the cable.
When voltage from car battery is higher than the
starter battery, the red and green LED will flash
alternately. No current output from the cable.
No damage, no fire. Red LED will flash slowly.
No current output from the cable.
When the internal temperature of the jumper
cable exceeds 90°C / 194°F, green LED will flash
slowly. No current output from the cable.
