High PoE Midspan and Splitters Installation Guide
AXIS T8123

Package contents

AXIS High PoE Midspan
Power cable (region specific)
Printed material

Functions and features

The AXIS T8123 High PoE Midspan 1-port injects 55V DC power into the spare pairs of the Ethernet
cabling. It maintains IEEE802.3af specification parameters while doubling the output power. These
power levels allowed a new range of Ethernet-based applications such as PTZ Cameras to use the
High PoE Midspan.

Preliminary steps

• Ensure AC power is applied to the AXIS T8123, using an operational AC cable with appropri-
ate ground connection.
• Ensure that output Ethernet cable is connected to the Data & Power Out port.
• Verify that a power ready Ethernet compatible device or splitter is connected.
Note:
Do not use a cross over cable between the AXIS T8123 output port and the powered device.
AXIS T8123 High PoE Midspan 1-port
Europe
UK
USA
Japan
Australia
Installation guide
Warranty document
Page 5
