Mounting/Montage
2
A
= 0,21 m
w
2
A
= 0,06 m
w
690
380
Wind projecting surface/Windangriffsfläche: A
Dimensions [mm]
w
L =
L =
Ø 42/48 mm: M10 x 45 mm
Ø 60 mm: M10 x 45 mm
Ø 60 mm: M10 x 30 mm
Ø 76 mm: M10 x 30 mm
= 0°
= 0°
5
17 Nm
5
0°/ 5°/10°/15°
0°/ 5°/10°/15°
17 Nm
5
2
