Thank you for buying a case from Inter-Tech. You got a high-quality case with a lot of individual controllable light effects and plenty space for
large graphics adapter and hard disks.
This case is made only for computer assembling and indoor use.
We recommend to read this manual carefully and to connect fans and controller as per description.
We assume no liability for damages caused by nonobservance of this manual. Keep this manual for later use.
Make sure that the case is isolated from electric grid when working on it.
Because LED work with less voltage the current is higher to get the same wattage. Therefore the fire hazard increases in case of improper
installation or use. Ensure that all cables are correct connected and fixed before starting the computer.
In case of strange noise, smell or smoke, cut the connection to the electric grid immediately.
We recommend to cut the computer from the electric grid in case of longer non-use.
If you want to dispose your computer, don´t dispose it with normal waste. Please bring it to the special collection points for electric waste.
Please ask you municipality for that. Cardboard and plastics from packaging can be disposed in the appropriate waste container of household
garbage.
We grant the legal implied warranty for this product. In case of warranty claim, please contact your dealer. The complete warranty terms are shown
on our website www.inter-tech.de.
Pos.
Description
A
Distance holder
Screws
B
C
Screws
D
Screws
E
Absorber
F
Screws
Screws
G
Washer
H
I
Cable tie
J
Fan mounting at back side
Fan mounting in front
Manual S-3901 / S-3906
Quantity
Use
for mainboard mounting
5
for mounting of m
ainboard
18
2,5" HDD
4
for power supply
8
f r o 3,5" HDD
8
f r o 3,5" HDD
f r o 3,5" HDD
2
for lower Front-Fan
4
f r o 2,5" HDD
8
4
for cable fixing
Tool
for mounting of mainboard distance holder
1
- You can mount one 120mm fan.
- Remove left side panel.
- Place the fan from ahead into position and fix it
with screws from behind(these screws are part
of the fan).
- You can mount up to three 120mm or two 140mm fans.
- Remove left side panel.
- Take off front panel by pulling the lower end of the front panel.
- Take care not to tear off the cables.
- Place the upper two fans from behind into position and fix it with screws from ahead (these
screws are part of the fan).
- Place the lower fan from behind into position and fix it with screws from behind (these
screws are included scope of delivery).
- Re-mount the front panel by pushing it onto the case, beginning at the top.
- Avoid to clamp cables.
and
Fan mounting on top
- You can mount up to two 120mm or 140mm
fans.
- Remove front panel by pulling the lower end of
the panel.
- Remove top panel by grabbing under the panel
and carefully pulling it up.
- Remove left side panel.
- Place the fan from below into position and fix it
with screws F from above(these screws are
part of the fan).
- Re-mount front and top panel in reverse order.
