REMOtE CONtROL

• Press once to lock doors - the turn lights gleam once and the
siren chips once
• If connected to power window closer output, the
windows will roll up automatically
• When locked, press and hold for about 3 seconds to
locate the vehicle - the turn lights gleam 3 times and the
siren chips 3 times
• Press once to unlock doors - the directional lights gleam twice and the siren chips twice
• When unlocked, press and hold for about 3 seconds to release the trunk
• Press once to lock doors - the directional lights gleam once the siren DOESN'T chip
• Press once to locate the vehicle - the directional lights gleam 15 times and the siren chips
15 times continuously
REMOtE CONtROL PROgRaMMiNg
1. Press the learning button on the control unit, the turn lights will flash once.
2. Press any key on the remote control.
3. The car will emit two sound signals and turn lights will flash once; which means learning
has been performed successfully.
4. User can program up to 4 remote controls with the same control unit.

SPECiFiCatiON

• Central lock system automation
• Car localization
• Trunk release
• Window closing
• Warning diode
• Sound / visual indication
• Push/pull force: 4-4,5 kg
• Remote control material: aluminum + ABS
• Operation range: up to 50 m
• Power supply: DC 12 V
• Set includes: master actuator, 3 slave actuator, 2 remote controls, control unit, cables
