M57
5
S-VIDEO OUT
Connect the S-VIDEO output of
the Audio Multiroom Server to
the S-VIDEO input of a suitable
PAL/NTSC TV (depending on
the supplied configuration) to
display the TV User Interface.
You may also need to switch
the TV to the relevant AUX
input to display the picture.
6
ETHERNET
The Ethernet port can be used
to connect the Audio Multiroom
Server to a high speed internet
connection. It may also be used
by supported software
applications to communicate
with the system. A shielded
Ethernet cable should be used
in conjunction with this
connection.
7
MODEM
The Modem port can be used
to connect the Audio Multiroom
Server to a standard analogue
telephone line for internet
access (using the supplied
cable).
8
VGA
The VGA connector may be
used to connect a VGA monitor
or a suitable Plasma screen for
displaying the TV User interface.
Controls & Connections
9
USB
Allows the Audio Multiroom
Server to communicate with
supported USB devices.
10 DIGITAL OUT - CO-
AXIAL
By connecting this jack to a
digital audio component (D/A
convertor, digital sound
processor etc.), digital signals
from the Audio Multiroom Server
can be transmitted directly from
the system without first being
converted to analogue.
11 DIGITAL IN - COAXIAL
High Quality recordings can be
made onto the Hard Disk of the
Audio Multiroom Server using a
coaxial connection from a
suitable device (such as
Minidisc or DAT).
12 ANALOGUE IN 1,2,3,4
Analogue sources (such as
cassette or vinyl LP) may be
recorded onto the Hard Disk of
the Audio Multiroom Server
using this connection.
13 PS2
Allows the Audio Multiroom
Server to communicate with
supported PS2 devices.
14 MAINS
Connect the supplied mains
lead to this connector to provide
power to the unit.
14
To be enabled in an optional future software update.
