E
English
3. The length of the audio
cable provides the op-
tion and flexibility of in-
stalling the module on
any available expansion
bracket slot at the rear
of the system chassis.
Remove the screw of
the bracket where you
want the audio module
installed then remove the bracket. Place the Bernstein audio
module on the expansion bracket slot then secure the module
by replacing the bracket screw you removed earlier.
Installing the VoIP Card (optional)
1. The cable included in the
VoIP kit is used to con-
nect the VoIP card to
the Bernstein audio
module.
2. Install the VoIP card into
an available expansion
slot - near the Bernstein
audio
installed earlier.
Important:
To use VoIP, make sure
the Bernstein audio
module installed earlier
uses Realtek ALC888T.
18
module you
Audio cable
VoIP cable
VoIP card
VoIP card
ALC888T Bernstein
audio module
