Introduction

About this manual

This document describes how to install the BSM-2 and
connect the unit to transducers and display units.
Separate installation instruction for transducers are
included with the transducer package.
The BSM-2 is compatible with the following displays and
systems:
NSE
-
NSO
-
NSS
-

The BSM-2 module layout

CoNNECTor
WATErTIGHT
CABLE GLANDS
ETHErNET
BSM-2 Installation manual | 5
GrouNDING
SCrEW
LED STATuS
INDICATorS
rEMovABLE
CovEr
